ABB
1SAE231111M0130
Product type: ESB25-30N-01
Installationsschütz 3S/0Ö, 24 V AC/DC
Description
4-polige Schütze ESB25..N mit 36 mm Baubreite steuern 3-phasige Lasten bis 25 A und stehen in unterschiedlichen Kontaktbelegungen und Spulenspannungen zur Verfügung. Sie schalten elektrische Heizgeräte, Warmwasserbereiter, Motoren für Pumpen, Lüftung und sonstige Antriebe ebenso wie Beleuchtungen. Durch eine integrierte Spulenbeschaltung arbeiten sie sowohl mit AC- als auch mit DC-Steuerspannungen. Die Geräte sind deshalb absolut brummfrei und leise beim Schalten. Ein als Zubehör linksseitig anbaubarer Hilfsschalter sowie Plombierkappen und ein Distanzstück ergänzen das Sortiment. ESB25..N haben Installationsdesign und erfüllen u.a. die Haushaltsnorm EN61095, sie sind daher besonders geeignet für den Verteilereinbau.
Read More
- Low Voltage Products and Systems
- Control Products
- Contactors
- Installation Contactors
| Thomas Hoffmann |
| +49 305 201 4443 |
| sales@zwodltd.com |
    |
     |
| Price: Please send request |
| Request Lead Time: app. 1 Day |
| Delivery Time: app. 4-5 Weeks Estimated delivery time to our warehouse in Berlin |
| Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025 |
- ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 1SAE231111M0130.
- See all ZWOD Sales and Logistics Ltd ABB products.
Multiples Of: 6
Product Specifications
| Product Attribute | Attribute Value |
|---|---|
| Weight | 0.23 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | DE |
| Dimensions (WxHxD) | 0.036x0.085x0.065 m |
| EAN code | |
| Product group | AQ |
| eclass | V11.0 : 27142308 |
| etim 5 | EC001653 - Installation contactor for distribution board |
| etim 6 | EC001653 - Installation contactor for distribution board |
| etim 7 | EC001653 - Installation contactor for distribution board |
| etim 8 | EC001653 - Installation contactor for distribution board |
| unspsc | 39121529 |
| standards | IEC/EN 60947-1IEC/EN 60947-4-1IEC/EN 61095UL 60947-1UL 60947-4-1 |
| rohs status | Following EU Directive 2011/65/EU |
| cb certificate | https://library.abb.com/d/1SAA920004-2001 |
| abs certificate | https://library.abb.com/d/1SAA920000-0101 |
| cqc certificate | https://library.abb.com/d/CQC2017010304993564, https://library.abb.com/d/CQC2017010304993565 |
| dnv certificate | https://library.abb.com/d/1SAA920000-0306 |
| eac certificate | https://library.abb.com/d/1SAA920001-2702 |
| number of poles | 3 |
| pollution degree | 3 |
| rina certificate | https://library.abb.com/d/1SAA920000-0801 |
| rmrs certificate | https://library.abb.com/d/1SAA920000-0705 |
| rohs information | https://library.abb.com/d/1SAD938506-0302 |
| culus certificate | https://library.abb.com/d/cUL_E191658 |
| tightening torque | Control Circuit 0.9 N·mMain Circuit 1 N·m |
| rated frequency (f) | Control Circuit 400 HzControl Circuit 50 HzControl Circuit 60 HzControl Circuit DCMain Circuit 50 HzMain Circuit 60 HzMain Circuit DC |
| degree of protection | IP20 |
| electrical durability | AC-1 (NO) 130000 cycleAC-3 (NO) 500000 cycleAC-7a (NO) 130000 cycleAC-7b (NO) 500000 cycle |
| mechanical durability | 1000000 cycle |
| wire stripping length | Control Circuit 7 mmMain Circuit 10 mm |
| ambient air temperature | Operation -25 ... +55 °CStorage -40 ... +80 °C |
| horsepower rating ul/csa | (220 ... 240 V AC) Single Phase, NO 1 Hp(220 ... 240 V AC) Three Phase, NO 3 Hp(440 ... 480 V AC) Single Phase, NO 2 Hp(440 ... 480 V AC) Three Phase, NO 5 Hp |
| recommended screw driver | Control Circuit Pozidriv 1Main Circuit Pozidriv 1 |
| tightening torque ul/csa | Control Circuit 8 in·lbMain Circuit 9 in·lb |
| environmental information | https://library.abb.com/d/1SAC200063H0009 |
| rated operational voltage | Main Circuit 220 V DCMain Circuit 400 V AC |
| number of main contacts nc | 0 |
| number of main contacts no | 3 |
| object classification code | Q |
| rated insulation voltage (ui) | 500 V |
| declaration of conformity - ce | https://library.abb.com/d/1SAD938506-0302 |
| declaration of conformity - ccc | https://library.abb.com/d/2020980304001312, https://library.abb.com/d/2020980304001314 |
| number of auxiliary contacts nc | 0 |
| number of auxiliary contacts no | 0 |
| connecting capacity main circuit | Flexible with Ferrule 1x 1.5 ... 10 mm2Flexible with Ferrule 2x 1.5 ... 2.5 mm2Flexible with Insulated Ferrule 1x 1.5 ... 10 mm2Flexible with Insulated Ferrule 2x 1.5 mm2Flexible 1x 1.5 ... 10 mm2Flexible 2x 1.5 ... 4 mm2Rigid 1x 1.5 ... 10 mm2Rigid 2x 1.5 ... 4 mm2 |
| declaration of conformity - ukca | https://library.abb.com/d/1SAD938501-1302 |
| maximum operating voltage ul/csa | Main Circuit 480 V AC |
| rated operational power ac-1 (pe) | (230 V) Single Phase, NO 5.8 kW(400 V) Three Phase, NO 17.3 kW |
| rated operational power ac-3 (pe) | (230 V) Single Phase, NO 1.3 kW(400 V) Three Phase, NO 4 kW |
| idea granular category code (igcc) | 4759 >> Installation contactor for distribution board |
| rated control circuit voltage (uc) | 24 V |
| rated operational power ac-7a (pe) | (230 V) Single Phase, NO 5.8 kW(400 V) Three Phase, NO 17.3 kW |
| rated operational power ac-7b (pe) | (230 V) Single Phase, NO 1.3 kW(400 V) Three Phase, NO 4 kW |
| connecting capacity control circuit | Flexible with Ferrule 1x 1 ... 2.5 mm2Flexible with Ferrule 2x 0.75 ... 1 mm2Flexible with Insulated Ferrule 1x 1 ... 2.5 mm2Flexible with Insulated Ferrule 2x 0.75 ... 1 mm2Flexible 1x 1 ... 4.0 mm2Flexible 2x 1 ... 2.5 mm2Rigid 1x 1 ... 4 mm2Rigid 2x 1 ... 2.5 mm2 |
| rated operational current ac-1 (ie) | (NO) 25 A |
| rated operational current ac-3 (ie) | (230 V) Single Phase, NO 9 A(400 V) Three Phase, NO 9 A |
| width in number of modular spacings | 2 |
| rated operational current ac-7a (ie) | (NO) 25 A |
| rated operational current ac-7b (ie) | (230 V) Single Phase, NO 9 A(400 V) Three Phase, NO 9 A |
| maximum operating altitude permissible | 2000 m |
| rated impulse withstand voltage (uimp) | 6 kV |
| connecting capacity main circuit ul/csa | Solid 16-8 AWGStranded 16-8 AWG |
| connecting capacity control circuit ul/csa | Solid 16-10 AWGStranded 16-10 AWG |
| resistance to shock acc. to iec 60068-2-27 | 11 ms Pulse 15g |
