| Weight | 0.046 KG / psc. |
| Commodity number | 85389099 |
| Country of origin | CN |
| Dimensions (WxHxD) | 0.045x0.1035x0.0673 m |
| EAN code | 4013614483950 |
| Product group | SE |
| eclass | V11.0 : 27371392 |
| etim 4 | EC002498 - Accessories for low-voltage switch technology |
| etim 5 | EC002498 - Accessories for low-voltage switch technology |
| etim 6 | EC002498 - Accessories for low-voltage switch technology |
| etim 7 | EC002498 - Accessories for low-voltage switch technology |
| etim 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| unspsc | 39122221 |
| standards | IEC/EN 60947-1IEC/EN 60947-4-1UL 60947-1UL 60947-4-1 |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| suitable for | EF19 |
| ul certificate | https://library.abb.com/d/E48139-19990512 |
| eac certificate | https://library.abb.com/d/1SAA941003-2701 |
| number of poles | 3 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SAD938519-0180 |
| dimension diagram | https://library.abb.com/d/1SAX100404F0001 |
| e-number (sweden) | 3210277 |
| tightening torque | Main Circuit 0.8 ... 1.5 N·m |
| e-number (finland) | 3800373 |
| rated frequency (f) | Main Circuit 50 HzMain Circuit 60 Hz |
| wire stripping length | Main Circuit 12 mm |
| recommended screw driver | Pozidriv 2 |
| tightening torque ul/csa | Main Circuit 7 ... 13 in·lb |
| number of protected poles | 3 |
| rated operational voltage | Auxiliary Circuit 600 V AC/DCMain Circuit 690 V AC |
| object classification code | F |
| rated insulation voltage (ui) | 690 V |
| declaration of conformity - ce | https://library.abb.com/d/1SAD938519-0180 |
| rated operational current (ie) | 18.9 A |
| connecting capacity main circuit | Flexible with Ferrule 1x 0.75 ... 2.5 mm2Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm2Flexible 1x 0.75 ... 2.5 mm2Rigid 1x 1 ... 4 mm2 |
| declaration of conformity - ukca | https://library.abb.com/d/1SAD938502-1180 |
| maximum operating voltage ul/csa | Main Circuit 600 V AC |
| data sheet, technical information | https://library.abb.com/d/2CDC107025D0201 |
| idea granular category code (igcc) | 5219 >> Switch part or accessory |
| rated operational current ac-3 (ie) | 18.9 A |
| rated impulse withstand voltage (uimp) | Main Circuit 6 kV |
| connecting capacity main circuit ul/csa | Flexible 1/2x 18-10 AWGStranded 1/2x 18-10 AWG |
