| Weight | 0.132 KG / psc. |
| Commodity number | 85389099 |
| Country of origin | BG |
| Dimensions (WxHxD) | 0.055x0.095x0.138 m |
| EAN code | 4013614501722 |
| Product group | SE |
| eclass | V11.0 : 27371392 |
| etim 5 | EC002498 - Accessories for low-voltage switch technology |
| etim 6 | EC002498 - Accessories for low-voltage switch technology |
| etim 7 | EC002498 - Accessories for low-voltage switch technology |
| etim 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| unspsc | 39122221 |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| suitable for | TF65 |
| ul certificate | https://library.abb.com/d/E48139-20130329 |
| number of poles | 3 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SAD938512-0187 |
| e-number (sweden) | 3210250 |
| mounting position | 1 ... 6 |
| tightening torque | Main Circuit 4.0 ... 4.5 N·m |
| rated frequency (f) | Main Circuit 60 HzMain Circuit 50 Hz |
| ampere rating ul/csa | 67 A |
| degree of protection | IP20 |
| wire stripping length | Main Circuit 17 mm |
| recommended screw driver | Pozidriv 2M6 |
| tightening torque ul/csa | Main Circuit 35 ... 40 in·lb |
| rated operational voltage | Main Circuit 690 V AC |
| rated insulation voltage (ui) | 390 V |
| declaration of conformity - ce | https://library.abb.com/d/1SAD938512-0187 |
| rated operational current (ie) | 67 A |
| connecting capacity main circuit | Flexible with Ferrule 1x 2.5 ... 35 mm2Flexible with Ferrule 2x 2.5 ... 10 mm2Flexible with Insulated Ferrule 1x 2.5 ... 35 mm2Flexible with Insulated Ferrule 1x 2.5 ... 10 mm2Flexible 1x 2.5 ... 35 mm2Flexible 2x 2.5 ... 16 mm2Rigid 1x 2.5 ... 35 mm2Rigid 2x 2.5 ... 16 mm2 |
| declaration of conformity - ukca | https://library.abb.com/d/1SAD938501-1187 |
| maximum operating voltage ul/csa | Main Circuit 600 V AC |
| idea granular category code (igcc) | 5219 >> Switch part or accessory |
| rated operational current ac-3 (ie) | 67 A |
| rated impulse withstand voltage (uimp) | Main Circuit 8 kV |
| connecting capacity main circuit ul/csa | Flexible 1x 12-2 AWGFlexible 2x 12-6 AWGStranded 1x 12-2 AWGStranded 2x 12-6 AWG |
| resistance to shock acc. to iec 60068-2-27 | 11 ms Pulse 25g |
| resistance to vibrations acc. to iec 60068-2-6 | 5g / 3 ... 150 Hz |
