| Weight | 0.19 KG / psc. |
| Commodity number | 85389099 |
| Country of origin | BG |
| Dimensions (WxHxD) | 0.07x0.157x0.102 m |
| EAN code | 4013614501524 |
| Product group | SE |
| eclass | V11.0 : 27371392 |
| etim 5 | EC002498 - Accessories for low-voltage switch technology |
| etim 6 | EC002498 - Accessories for low-voltage switch technology |
| etim 7 | EC002498 - Accessories for low-voltage switch technology |
| etim 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| unspsc | 39122221 |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| suitable for | TF96EF96 |
| ul certificate | https://library.abb.com/d/E48139-20130329 |
| number of poles | 3 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SAD938512-0187, https://library.abb.com/d/1SAD938519-0180 |
| e-number (sweden) | 3210251 |
| mounting position | 1 ... 6 |
| tightening torque | Main Circuit 6 N·m |
| rated frequency (f) | Main Circuit 60 HzMain Circuit 50 Hz |
| degree of protection | IP20 |
| wire stripping length | Main Circuit 22 mm |
| recommended screw driver | M8Hexagon 4 |
| tightening torque ul/csa | Main Circuit 55 in·lb |
| rated operational voltage | Main Circuit 1000 V AC |
| rated insulation voltage (ui) | 1000 V |
| declaration of conformity - ce | https://library.abb.com/d/1SAD938512-0187, https://library.abb.com/d/1SAD938519-0180 |
| connecting capacity main circuit | Flexible with Ferrule 1x 6 ... 50 mm2Flexible with Ferrule 2x 6 ... 35 mm2Flexible with Insulated Ferrule 1x 6 ... 50 mm2Flexible with Insulated Ferrule 2x 6 ... 16 mm2Flexible 1x 6 ... 70 mm2Flexible 2x 6 ... 35 mm2Rigid 1x 6 ... 70 mm2Rigid 2x 6 ... 35 mm2 |
| declaration of conformity - ukca | https://library.abb.com/d/1SAD938501-1187, https://library.abb.com/d/1SAD938502-1180 |
| maximum operating voltage ul/csa | Main Circuit 600 V AC |
| idea granular category code (igcc) | 5219 >> Switch part or accessory |
| rated impulse withstand voltage (uimp) | Main Circuit 8 kV |
| connecting capacity main circuit ul/csa | Flexible 1x 8-1 AWGFlexible 2x 8-3 AWGStranded 1x 8-1 AWGStranded 2x 8-2 AWG |
| resistance to shock acc. to iec 60068-2-27 | 11 ms Pulse 25g |
| resistance to vibrations acc. to iec 60068-2-6 | 5g / 3 ... 150 Hz |
