| Weight | 0.5 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | LT |
| Dimensions (WxHxD) | 0.13x0.15x0.06 m |
| EAN code | 6417019131207 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| standards | IEC 60947-1, -3 |
| power loss | at Rated Operating Conditions per Pole 1.6 W |
| handle type | Selector handle |
| rohs status | Following EU Directive 2011/65/EU |
| handle color | Red / Yellow |
| neutral type | Fixed neutral |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| bv certificate | https://library.abb.com/d/1SCC340018D0204 |
| number of poles | 3 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC340075D0201 |
| reach declaration | https://library.abb.com/d/1SCC340076D0201 |
| dnv gl certificate | https://library.abb.com/d/1SCC340045D0203 |
| enclosure material | Plastic |
| cable cross-section | 0.75 ... 10 mm2 |
| mechanical drawings | https://library.abb.com/d/OTPK151385SM25.stp |
| cable entry position | Up/Down |
| degree of protection | acc. to IEC 60529 IP65 |
| cable outlets per side | 2xM25+M16 / 2xM25+M16 |
| impact resistance rating | Housing IK08 |
| position of pe terminals | Top In - Bottom Out |
| rated operational voltage | Main Circuit 750 V |
| mounted auxiliary contacts | 0 NO, 0 NC |
| object classification code | Q |
| position of line terminals | Top In - Bottom Out |
| position of neutral terminals | Top In - Bottom Out |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 750 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC340003D2704 |
| number of auxiliary contacts nc | 0 |
| number of auxiliary contacts no | 0 |
| connecting capacity main circuit | Screw Clamp 0.75 ... 10 mm2Screw Clamp / PE Terminal 2pc,1.5 ... 10 mm2 |
| data sheet, technical information | https://library.abb.com/d/1SCC340015C0201 |
| maximum mounted auxiliary contacts | 2 NO, 2 NC |
| conventional thermal current (ithe) | Fully Enclosed 40 A |
| rated operational power ac-23a (pe) | (380 ... 415 V) 11 kW(500 V) 11 kW(690 V) 11 kW |
| rated operational current ac-21a (ie) | (380 ... 415 V) 40 A(500 V) 40 A(690 V) 40 A |
| rated operational current ac-22a (ie) | (380 ... 415 V) 40 A(690 V) 40 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 23 A(500 V) 23 A(690 V) 12 A |
| rated impulse withstand voltage (uimp) | 0.5 kV |
| rated short-circuit making capacity (icm) | (690 V AC) 0.705 kA |
| rated short-time withstand current low voltage (icw) | for 1 s 0.5 kA |
