1SCA022703R2340

Product type: OFAA0GG100

OFAA0GG100 HRC FUSE LINK

Datasheet

RoHS Compliant

Description

Fuselink, rated current 100A, size NH0, rated voltage 690VAC / 400VDC, utilization category gG, rated breaking capacity 80 kA (AC) / 80 (kA DC) OFAA0GG100

Low Voltage Products and Systems
Fusegear
Fuse Links

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 1SCA022703R2340.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 3

Product Specifications

Product Attribute	Attribute Value
Weight	0.21 KG / psc.
Commodity number	85361090
Country of origin	HU
Dimensions (WxHxD)	70x60x85 mm
EAN code	6417019227511
Product group	FA
eclass	V11.1 : 27142005
etim 5	EC000055 - Low Voltage HRC fuse
etim 6	EC000055 - Low Voltage HRC fuse
etim 7	EC000055 - Low Voltage HRC fuse
etim 8	EC000055 - Knife blade fuse
fuse size	NH0
fuse type	gG
standards	IEC 60269
power loss	9.4 W
fuse system	DIN
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
e-number (finland)	3110290
rated current (in)	100 A
rated voltage (ur)	690 V
environmental information	https://library.abb.com/d/1SCC317009D0201
declaration of conformity - ce	https://library.abb.com/d/1SCC317005D2706
data sheet, technical information	https://library.abb.com/d/1SCC317001C0201
