| Weight | 1.3 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | FI |
| Dimensions (WxHxD) | 0.193x0.1x0.086 m |
| EAN code | 6417019391502 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| unspsc | 39122233 |
| standards | UL 98 / IEC60947-3 |
| power loss | 4 W |
| handle type | Handle and shaft not included |
| handle color | Black |
| mounting type | Base mounting |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| operating mode | Front operated |
| number of poles | 4 |
| transition type | Open |
| fourth pole type | Switched - Simultaneous Function |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC301183D0201 |
| e-number (finland) | 3601404 |
| cable cross-section | 10 ... 70 mm2 |
| ampere rating ul/csa | 100 A |
| degree of protection | Front IP20 |
| fourth pole position | Right Side |
| mechanical durability | 6000 cycle |
| distance between phases | Standard |
| horsepower rating ul/csa | (acc. to UL 200 V) 30 Hp(acc. to UL 208 V) 30 Hp(acc. to UL 240 V) 30 Hp(acc. to UL 480 V) 50 Hp(acc. to UL 600 V) 50 Hp |
| rated operational voltage | 750 V |
| object classification code | Q |
| position of line terminals | Top In - Bottom Out, Bottom In - Top Out |
| switches operating mechanism | Mechanism on Top of the Switch |
| rated insulation voltage (ui) | 750 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC303021D0201 |
| data sheet, technical information | https://library.abb.com/d/1SCC303003C0201 |
| conventional thermal current (ithe) | Fully Enclosed 115 A |
| rated operational power ac-23a (pe) | (380 ... 415 V) 37 kW(500 V) 37 kW(690 V) 37 kW |
| rated operational current ac-21a (ie) | (380 ... 415 V) 100 A(500 V) 100 A(690 V) 100 A |
| rated operational current ac-22a (ie) | (380 ... 415 V) 100 A(500 V) 100 A(690 V) 100 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 80 A(500 V) 60 A(690 V) 40 A |
| rated impulse withstand voltage (uimp) | 8 kV |
| conventional free-air thermal current (ith) | q = 40 °C 115 A |
| rated short-time withstand current low voltage (icw) | for 1 s 2.5 kiloampere rms |
