| Weight | 6 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | FI |
| Dimensions (WxHxD) | 240x218x270 mm |
| EAN code | 6417019401621 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| power loss | 6.5 W |
| handle type | Handle and shaft included |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| handle color | Black |
| mounting type | Base mounting |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| operating mode | Front operated |
| number of poles | 3 |
| transition type | Closed |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC011020D0201 |
| reach declaration | https://library.abb.com/d/1SCC011021D0201 |
| e-number (finland) | 3641618 |
| degree of protection | Front IP20 |
| distance between phases | Standard |
| environmental information | https://library.abb.com/d/1SCC303050D0201 |
| rated operational voltage | 1000 V |
| object classification code | Q |
| position of line terminals | Top In - Bottom Out, Bottom In - Top Out |
| switches operating mechanism | Mechanism at the End of the Switch03 (Left Side) |
| rated insulation voltage (ui) | 1000 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC303046D2702 |
| data sheet, technical information | https://library.abb.com/d/1SCC303003C0201 |
| conventional thermal current (ithe) | Fully Enclosed 315 A |
| rated operational power ac-23a (pe) | (380 ... 415 V) 160 kW(500 V) 220 kW(690 V) 315 kW |
| rated operational current ac-21a (ie) | (380 ... 415 V) 315 A(500 V) 315 A(690 V) 315 A |
| rated operational current ac-22a (ie) | (380 ... 415 V) 315 A(500 V) 315 A(690 V) 315 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 315 A(500 V) 315 A(690 V) 315 A |
| rated operational current ac-31b (ie) | (380 ... 415 V) 315 A |
| rated operational current ac-33b (ie) | (380 ... 415 V) 315 A |
| rated impulse withstand voltage (uimp) | 12 kV |
| conventional free-air thermal current (ith) | q = 40 °C 315 A |
| rated short-time withstand current low voltage (icw) | for 1 s 15 kiloampere rms |
