| Weight | 1 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | FI |
| Dimensions (WxHxD) | 115x115x215 mm |
| EAN code | 6417019538587 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| lock type | Yes |
| standards | IEC 60947-3 |
| power loss | at Rated Operating Conditions per Pole 6.3 W |
| handle type | Direct mounted handle |
| rohs status | Following EU Directive 2011/65/EU |
| handle color | Black |
| mounting type | Base mounting |
| terminal type | Screw Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| operating mode | Front operated |
| number of poles | 4 |
| fourth pole type | Switched - Simultaneous Function |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC301200D2702 |
| special functions | No |
| tightening torque | acc. IEC 60947-1 6 N·m |
| cable cross-section | Cu 10 ... 70 mm2 |
| degree of protection | Front IP20 |
| fourth pole position | Right Side |
| mechanical durability | 20000 |
| distance between phases | Standard |
| motor operational voltage | 110 ... 240 V AC/DC |
| rated operational voltage | Main Circuit 750 V |
| object classification code | Q |
| position of line terminals | Top In - Bottom Out |
| switches operating mechanism | Mechanism at the End of the Switch |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 750 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC301200D0201 |
| data sheet, technical information | https://library.abb.com/d/1SCC301020C0201 |
| conventional thermal current (ithe) | Fully Enclosed 125 A |
| rated operational power ac-23a (pe) | (220 ... 240 V) 22 kW(400 ... 415 V) 45 kW(500 V) 45 kW(690 V) 45 kW |
| rated operational current ac-21a (ie) | (380 ... 415 V) 125 A(500 V) 125 A(690 V) 125 A |
| rated operational current ac-22a (ie) | (380 ... 415 V) 125 A(500 V) 125 A(690 V) 125 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 90 A(500 V) 70 A(690 V) 50 A |
| rated impulse withstand voltage (uimp) | 8 kV |
| rated short-circuit making capacity (icm) | (690 V) 3.6 kA |
| conventional free-air thermal current (ith) | q = 40 °C 125 A |
| rated conditional short-circuit current (inc) | (125 A fuse, 415 V) 50 kA(125 A fuse, 690 V) 18 kA(63 A fuse, 690 V) 50 kA |
| rated short-time withstand current low voltage (icw) | for 1 s 2.5 kA |
