| Weight | 69.6 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | FI |
| Dimensions (WxHxD) | 444x385x714 mm |
| EAN code | 6417019724522 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| lock type | Yes |
| standards | UL 98 / CSA C22.2 NO.4 |
| power loss | at Rated Operating Conditions per Pole 96 W |
| handle type | Handle and shaft included |
| rohs status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| handle color | Black |
| ampere rating | 1600 A |
| mounting type | Base mounting |
| terminal type | Lug terminals |
| weee category | 4. Large Equipment (Any External Dimension More Than 50 cm) |
| operating mode | Front operated |
| ul certificate | https://library.abb.com/d/cULus certificate OT1600-2000 |
| cul certificate | https://library.abb.com/d/cULus certificate OT1600-2000 |
| number of poles | 4 |
| vde certificate | https://library.abb.com/d/No certification needed |
| atex certificate | https://library.abb.com/d/No certification needed |
| fourth pole type | Switched - Simultaneous Function |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC011020D0201 |
| reach declaration | https://library.abb.com/d/1SCC011021D0201 |
| special functions | No |
| tightening torque | acc. IEC 60947-1 56 N·m |
| mechanical drawings | https://library.abb.com/d/1SCC307649F0001, https://library.abb.com/d/1SCC307648F0001, https://library.abb.com/d/OT1600-2000U13.stp, https://library.abb.com/d/OT1600-2000U13.igs |
| degree of protection | Front IP00 |
| fourth pole position | Right Side |
| mechanical durability | 2500 |
| distance between phases | Standard |
| tightening torque ul/csa | 500 in·lb |
| rated operational voltage | Main Circuit 1000 V |
| object classification code | Q |
| position of line terminals | Top In - Bottom OutBottom In - Top Out |
| switches operating mechanism | Mechanism Between the Poles13 (Between the Poles) |
| declaration of conformity - ce | https://library.abb.com/d/No declaration needed |
| maximum operating voltage ul/csa | 600 V |
| conventional thermal current (ithe) | Fully Enclosed 1600 A |
| rated impulse withstand voltage (uimp) | 12 kV |
| rated short-time withstand current low voltage (icw) | for 1 s 50 kA |
