| Weight | 14.8 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | FI |
| Dimensions (WxHxD) | 0.4x0.4x0.23 m |
| EAN code | 6417019779201 |
| Product group | FA |
| eclass | V11.1 : 27371403 |
| etim 5 | EC000216 - Switch disconnector |
| etim 6 | EC000216 - Switch disconnector |
| etim 7 | EC000216 - Switch disconnector |
| etim 8 | EC000216 - Switch disconnector |
| standards | IEC 60947-1, -3 |
| handle type | Pistol handle |
| rohs status | Following EU Directive 2011/65/EU |
| handle color | Black |
| neutral type | No neutral terminal |
| terminal type | Screw Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| enclosure type | MSC |
| number of poles | 3 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/1SCC340075D0201 |
| e-number (sweden) | 3134562 |
| reach declaration | https://library.abb.com/d/1SCC340076D0201 |
| special functions | EMC |
| tightening torque | 6 N·m |
| e-number (finland) | 3638797 |
| enclosure material | Steel sheet |
| cable cross-section | 10 ... 70 mm2 |
| mechanical drawings | https://library.abb.com/d/OTKM404023PBL4R.stp |
| cable entry position | Down/Down |
| degree of protection | acc. to IEC 60529 IP65 |
| cable outlets per side | Blank / 4xring-flange, Knock-outs: 3x10mm, 12.5mm, 20.5mm, 25.5mm, 32.5mm |
| impact resistance rating | Housing IK09 |
| rated operational voltage | Main Circuit 1000 V |
| mounted auxiliary contacts | 1 NO, 1 NC |
| object classification code | Q |
| position of line terminals | Bottom In - Bottom Out |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 1000 V |
| declaration of conformity - ce | https://library.abb.com/d/1SCC340002D2703 |
| number of auxiliary contacts nc | 1 |
| number of auxiliary contacts no | 1 |
| connecting capacity main circuit | Screw Clamp 10 ... 70 mm2Screw Clamp / PE Terminal 2pc,10 ... 70 mm2 |
| data sheet, technical information | https://library.abb.com/d/1SCC340015C0201 |
| maximum mounted auxiliary contacts | 2 NO, 1 NC |
| conventional thermal current (ithe) | Fully Enclosed 125 A |
| rated operational power ac-23a (pe) | (380 ... 415 V) 55 kW(500 V) 75 kW(690 V) 110 kW |
| rated operational current ac-22a (ie) | (380 ... 415 V) 125 A(500 V) 125 A(690 V) 125 A |
| rated operational current ac-23a (ie) | (380 ... 415 V) 125 A(500 V) 125 A(690 V) 125 A |
| rated impulse withstand voltage (uimp) | 12 kV |
| rated short-circuit making capacity (icm) | (690 V AC) 12 kA |
| rated conditional short-circuit current (inc) | 24 kA |
| rated short-time withstand current low voltage (icw) | for 1 s 4 kA |
