ABB

1SCA151162R1001

Product type: OFAZ1S1

Sicherungsunterteil 1-polig Berührungsschutz IP20 Anschlussschienenbreite 35 mm

Datasheet

Description

Sicherungsunterteile OFAZ und OFAX Die Sicherungsunterteile können in Kombination mit NH-Sicherungseinsätzen nach IEC 60269-2 und DIN VDE 0636-2 und Trennmessern eingesetzt werden.

Low Voltage Products and Systems
Fusegear
Fuse Bases

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 4-5 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 1SCA151162R1001.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 3

Product Specifications

Product Attribute	Attribute Value
Weight	0.59 KG / psc.
Commodity number	85389099
Country of origin	SI
Dimensions (WxHxD)	0.078x0.245x0.112 m
EAN code	6417019814865
Product group	FA
eclass	V11.1 : 27142106
etim 5	EC000216 - Switch disconnector
etim 6	EC000216 - Switch disconnector
etim 7	EC000067 - Low Voltage HRC fuse base
etim 8	EC000067 - Low Voltage HRC fuse base
fuse size	NH0
standards	IEC
power loss	at Rated Operating Conditions per Pole 32 W
fuse system	DIN
rohs status	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
mounting type	Baseplate
terminal type	Bolt
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
number of poles	1
pollution degree	3
rohs information	https://library.abb.com/d/1SCC011020D0201
reach declaration	https://library.abb.com/d/1SCC011021D0201
special functions	IP20, full protection
tightening torque	acc. IEC 60947-1 32 N·m
e-number (finland)	3109918
rated current (in)	250 A
degree of protection	IP20
rated operational voltage	690 V AC
object classification code	F
rated insulation voltage (ui)	1000 V AC
declaration of conformity - ce	https://library.abb.com/d/1SCC316005D2701
data sheet, technical information	https://library.abb.com/d/1SCC316001K0201
rated impulse withstand voltage (uimp)	6 kV
