1SDA102446R1
ABB

1SDA102446R1

Product type: XT5N 600 TMA 600-6000 3p FF UL

XT5N 600 TMA 600-6000 3P F F UL Leistungsschalter XT5N 3P UL-CSA

Description

Kompaktleistungsschalter für Anlagenschutz gemäß EN 60947-2 (DIN VDE 0660, Teil 101), Kompaktlasttrennschalter gemäß EN 60947-3 (DIN VDE 0660, Teil 107). Die Kompaktleistungs- / Lasttrennschalter Tmax XT entsprechen den unterschiedlichen Anlagenanforderungen von Gleich- und Wechselstromnetzen. Tmax XT mit thermomagnetischen- oder elektronischen Auslösern sind einsetzbar zum Schutz von Energieverteilungen, Kabeln, Generatoren und Motoren. Viele dieser Leistungsschalter können auch in Kommunikationssystemen benutzt werden. Umfangreiche Anschlussumbausätze, mechanisches und elektrisches Zubehör sowie Versionsumbausätze (steckbar / ausfahrbar) stehen zur Verfügung. Verschiedene Feldbus und IP Kommunikationsprotokolle können zum Einsatz kommen. Der Installationsprozess wird, dank der Bluetooth- und Ekip-Konnektivität für mobile Geräte, vereinfacht. Die in die SACE Tmax XT-Serie integrierte Konnektivität verknüpft Smartphones, Tablets und PCs in Echtzeit mit Datenanalysetools auf der ABB AbilityTM Cloud-Plattform.
Read More
  • Low Voltage Products and Systems
  • Circuit Breakers
  • Moulded Case Circuit Breakers
  • Tmax XT
Contact Person
Thomas Hoffmann
+49 305 201 4443
sales@zwodltd.com
Payment
Bank TransferVisaMastercardPayPal
Worldwide shipping
DHLUnited Parcel ServiceFedEx ExpressTNT ExpressDB Schenker
Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 4-5 Weeks
Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin
individually for each client according to INCOM TERMS 2025
Multiples Of: 1
Product Specifications
Product AttributeAttribute Value
Weight4.579 KG / psc.
Commodity number85389099
Country of originIT
Dimensions (WxHxD)0.14x0.205x0.104 m
EAN code8056221021777
Product groupLA
eclass V11.1 : 27370409
etim 6 EC000228 - Power circuit-breaker for trafo/generator/installation prot.
etim 7 EC000228 - Power circuit-breaker for trafo/generator/installation protection
etim 8 EC000228 - Power circuit-breaker for trafo/generator/installation protection
release TMA
version F
sub-type XT5
standards UL
power loss at Rated Operating Conditions per Pole 46 W
rohs status Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
current type AC/DC
product name Moulded Case Circuit Breaker
release type TM
setting range 420...600 A
weee category 5. Small Equipment (No External Dimension More Than 50 cm)
order multiple 1 piece
wiring diagram https://library.abb.com/d/1SDM000005A1001
number of poles 3
rohs information https://library.abb.com/d/9AKK108466A1424
product main type SACE Tmax XT
reach declaration https://library.abb.com/d/9AKK108466A1425
rated current (in) 600 A
mechanical drawings https://library.abb.com/d/1SDH002011A1101
mechanical durability 240 cycles per hour20000 cycle
order code us and canada XT5NU360BBFF000XXX
terminal connection type Fixed Circuit-Breakers
environmental information https://library.abb.com/d/9AKK107991A8215
rated operational voltage 600 V AC600 V DC
suitable for product class SACE Tmax XT
declaration of conformity - ce https://library.abb.com/d/9AKK107680A2824
short-circuit performance level N
rated uninterrupted current (iu) 600 A
data sheet, technical information https://library.abb.com/d/1SDC210200D0206, https://library.abb.com/d/1SDC210199D0206
interrupting rating acc. to ul489 (240 V AC) 65 kA(480 V AC) 35 kA(600 V AC) 18 kA(250 V DC) 2 Poles in Series 35 kA(500 V DC) 2 Poles in Series 25 kA(600 V DC) 3 Poles in Series 16 kA
circuit breaker type to be associated Power Distribution
rated instantaneous short-circuit current setting (ii) 3000...6000 A
