| Weight | 0.049 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | CH |
| Dimensions (WxHxD) | 0.009x0.085x0.068 m |
| EAN code | 7612270938858 |
| Product group | AR |
| cn8 | 85365053 |
| color | Black |
| eclass | V11.0 : 27142302 |
| etim 7 | EC001546 - Push button for distribution board |
| etim 8 | EC001546 - Push button for distribution board |
| remarks | Sealable in the On and Off positions |
| standards | EN60068-2-1EN60068-2-2EN60068-2-30DIN EN 60669-1VDE 0632-1UL508 |
| power loss | 0.5 W |
| power watt | 0.72 W |
| rohs status | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| switch type | Double Interrupting Contacts |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| cb certificate | https://library.abb.com/d/9AKK108466A3845 |
| weee b2c / b2b | Business To Consumer |
| ccc certificate | https://library.abb.com/d/9AKK108466A3830 |
| eac certificate | https://library.abb.com/d/9AKK107991A4779 |
| number of poles | 2 |
| vde certificate | https://library.abb.com/d/9AKK107991A9822 |
| options provided | 1 NO + 1 NC |
| rohs information | https://library.abb.com/d/2CCC413008D0206 |
| tightening torque | 1.2-1.5 N·m |
| e-number (finland) | 2312349 |
| eplan catalog tree | Electrical engineering / Sensor, switch, and pushbutton / Switch , pushbutton |
| product net length | 93 mm |
| rated current (in) | 16 A |
| rated voltage (ur) | Lamp 48 ... 48 V |
| built-in depth (t2) | 75 mm |
| connecting capacity | Solid 1x1...6 mm2Solid 2x2.5 mm2Flexible 1x0.75...2x2.5 mm2 |
| rated frequency (f) | 50/60 Hz |
| degree of protection | IP20 |
| control element color | Black |
| material of conductor | Copper |
| number of contacts co | 0 |
| number of contacts nc | 1 |
| number of contacts no | 1 |
| e-number (switzerland) | 467560258 |
| ambient air temperature | Operation -25...+55 °CStorage -40...+70 °C |
| environmental information | https://library.abb.com/d/2CCC441003C0201 |
| maximum switching voltage | 250 V |
| rated operational voltage | acc. to EN 250 V ACacc. To UL 508 240 V AC |
| number of main contacts nc | 1 |
| number of main contacts no | 1 |
| object classification code | S |
| declaration of conformity - ce | https://library.abb.com/d/2CCC441014D0201 |
| data sheet, technical information | https://library.abb.com/d/2CCC441003C0101 |
| width in number of modular spacings | 0.5 |
| number of auxiliary contacts co (spdt) | 0 |
