| Weight | 0.04 KG / psc. |
| Commodity number | 85365080 |
| Country of origin | CH |
| Dimensions (WxHxD) | 0.009x0.085x0.068 m |
| EAN code | 7612270939305 |
| Product group | AR |
| cn8 | 85365053 |
| color | Green |
| eclass | V11.0 : 27142324 |
| etim 7 | EC001657 - Indicator light for distribution board |
| etim 8 | EC001657 - Indicator light for distribution board |
| remarks | Sealable in the On and Off positions |
| standards | EN60068-2-1EN60068-2-2EN60068-2-30DIN EN 62094-1UL508 |
| lamp color | Green |
| power loss | 0.47-1 W |
| power watt | 0.47 W |
| rohs status | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| switch type | Double Interrupting Contacts |
| service life | LED Indicator 50000 hour |
| voltage range | 115 ... 250 V AC |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| cb certificate | https://library.abb.com/d/9AKK108466A3847 |
| number of leds | 2 |
| weee b2c / b2b | Business To Consumer |
| eac certificate | https://library.abb.com/d/9AKK107991A4779 |
| vde certificate | https://library.abb.com/d/9AKK108466A3837 |
| rohs information | https://library.abb.com/d/2CCC413008D0206 |
| e-number (sweden) | 2102813 |
| tightening torque | 1.2-1.5 N·m |
| e-number (finland) | 2312306 |
| eplan catalog tree | Electrical engineering / Sensor, switch, and pushbutton / Switch , pushbutton |
| product net length | 93 mm |
| rated current (in) | 16 A |
| rated voltage (ur) | 250 V |
| built-in depth (t2) | 59 mm |
| connecting capacity | Solid 1x1...6 mm2Solid 2x2.5 mm2Flexible 1x0.75...2x2.5 mm2 |
| rated frequency (f) | 50/60 Hz |
| degree of protection | IP20 |
| material of conductor | Copper |
| e-number (switzerland) | 472252638 |
| ambient air temperature | Operation -25...+55 °CStorage -40...+70 °C |
| auxiliary voltage ac/dc | LED Indicator 115...250 V AC |
| environmental information | https://library.abb.com/d/2CCC441002C0201 |
| eplan function definition | Signal lamp / Lamp, single / Lamp, single X1_X2 |
| rated operational voltage | 115 ... 230 V |
| object classification code | P |
| rated insulation voltage (ui) | 250 V |
| declaration of conformity - ce | https://library.abb.com/d/2CCC441015D0201 |
| data sheet, technical information | https://library.abb.com/d/2CCC441003C0101 |
| short-circuit current rating (sccr) | 3 kA |
| width in number of modular spacings | 0.5 |
| rated impulse withstand voltage (uimp) | 4 kV |
