ABB

2CCF330034A0001

Product type: SU401M-K32

SU401M-K32 Miniature circuit breaker

Datasheet

Description

ABB Miniature circuit breaker SMISSLINE TP,1P, Tripping characteristic K, Rated breaking capacity acc. UL489 10kA

Low Voltage Products and Systems
Modular DIN Rail Products
Plug-in Distribution Systems
Miniature Circuit Breakers MCBs

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 2CCF330034A0001.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.114 KG / psc.
Commodity number	85362020
Country of origin	CH
Dimensions (WxHxD)	18x84x102 mm
EAN code	7612271493271
Product group	AF
cn8	85362020
eclass	V11.0 : 27141901
etim 7	EC000042 - Miniature circuit breaker (MCB)
etim 8	EC000042 - Miniature circuit breaker (MCB)
power loss	3 W
rohs status	Following EU Directive 2002/95/EC August 18, 2005 and amendment
suitable for	SMISSLINE TP
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
weee b2c / b2b	Business To Business
number of poles	1
actuator marking	I / O
pollution degree	3
rohs information	https://library.abb.com/d/2CCC413008D0206_RoHS
dimension diagram	https://library.abb.com/d/9AKK107492A6192
mounting position	Any
tightening torque	2.8 N·m
eplan catalog tree	Electrical engineering / Protection devices / General
input voltage type	AC
rated current (in)	32 A
built-in depth (t2)	92 mm
connecting capacity	Rigid 35 mm2
rated frequency (f)	50 ... 60 Hz
degree of protection	IP20
electrical endurance	10000 cycle
mechanical endurance	10000 cycle
overvoltage category	III
accessories available	Yes
energy limiting class	3
ambient air temperature	Operation -25 ... +55 °CStorage -40 ... +70 °C
power supply connection	Arbitrary
tripping characteristic	K
recommended screw driver	Pozidriv 2
number of protected poles	1
rated operational voltage	acc. to IEC 60898-1 240 V
object classification code	F
suitable for product class	SMISSLINE TP
contact position indication	Red ON / Green OFF
rated insulation voltage (ui)	acc. to IEC/EN 60664-1 250 V
declaration of conformity - ce	https://library.abb.com/d/No declaration needed
data sheet, technical information	https://library.abb.com/d/9AKK107492A6192
reference ambient air temperature	40 °C
width in number of modular spacings	18
rated impulse withstand voltage (uimp)	4 kV
resistance to vibrations acc. to iec 60068-2-6	2...13.2 Hz/1 mm13.2...100Hz/0.7 g, 5 cycles5...150 ... 5 Hz/1 g, 4 waves
rated ultimate short-circuit breaking capacity (icu)	(230 V) 10 kA(400 V) 10 kA
