ABB

2CCS801901R0599

Product type: S801S-SCL63-SR

Kurzschlussstrombegrenzer, 1polig, 63A 690V AC, 50 kA, IEC 90647-2, Uimp=8kV

Datasheet

Description

Selbstrückstellender Kurzschlussstrombegrenzer Der S800-SCL-SR kann zusammen mit dem Hocheistungsautomaten S800P, S800S, S800N, S800C oder Motorschutzschaltern eingesetzt werden. Der S800-SCL-SR begrenzt den Kurzschlussstrom und hilft bei der Löschung, bis das dem Fehler nächstgelegene Schaltgerät auslöst. In dieser gesamten Zeit ist der Stromfluss zu den nachgeschalteten Schaltgeräten sichergestellt, was ihn zur idealen Lösung des Gruppenschutzes macht. Denn bis auf den fehlerbehafteten Abgang bleiben alle anderen parallelen Abgänge weiterhin in Betrieb.

Low Voltage Products and Systems
Modular DIN Rail Products
High Performance Circuit Breakers HPCBs Accessories

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 2CCS801901R0599.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.25 KG / psc.
Commodity number	85363030
Country of origin	CH
Dimensions (WxHxD)	0.027x0.142x0.083 m
EAN code	7612271412036
Product group	AF
cn8	85362020
eclass	V11.0 : 27370416
etim 7	EC000239 - Current limiter
etim 8	EC000239 - Current limiter
standards	IEC 60947-2IEC 60947-4-1
power loss	3.6 Wat Rated Operating Conditions per Pole 3.6 W
rohs status	Following EU Directive 2011/65/EU
suitable for	S800S
mounting type	DIN rail
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
weee b2c / b2b	Business To Business
number of poles	1
rohs information	https://library.abb.com/d/2CCC413015D0601, https://library.abb.com/d/9AKK107680A3903
product net length	54 mm
rated current (in)	63 A
apparent power output	Secondary 25200 V·A
environmental information	https://library.abb.com/d/2CCY413207D0203
rated operational voltage	Auxiliary Circuit 400 / 690 V
object classification code	F
declaration of conformity - ce	https://library.abb.com/d/2CCC413015D0601
rated operational current (ie)	63 A
rated uninterrupted current (iu)	63 A
data sheet, technical information	https://library.abb.com/d/2CCC413003C0208
rated impulse withstand voltage (uimp)	8 kV
rated conditional short-circuit current (inc)	50 kA
rated service short-circuit breaking capacity (ics)	(240 / 415 V AC) 100 kA(254 / 440 V AC) 100 kA(289 / 500 V AC) 65 kA(400 / 690 V AC) 50 kA
rated ultimate short-circuit breaking capacity (icu)	(240 / 415 V AC) 100 kA(254 / 440 V AC) 100 kA(289 / 500 V AC) 65 kA(400 / 690 V AC) 50 kA
