| Weight | 0.735 KG / psc. |
| Commodity number | 85362010 |
| Country of origin | CH |
| Dimensions (WxHxD) | 0.081x0.095x0.083 m |
| EAN code | 7612271203160 |
| Product group | AF |
| cn8 | 85362020 |
| size | 3 modules |
| eclass | V11.0 : 27141901 |
| etim 7 | EC000042 - Miniature circuit breaker (MCB) |
| etim 8 | EC000042 - Miniature circuit breaker (MCB) |
| standards | IEC/EN 60947-2 |
| power loss | 18.6 Wat Rated Operating Conditions per Pole 6.2 W |
| rohs status | Following EU Directive 2011/65/EU |
| release type | B |
| frequency (f) | 0...0 Hz |
| terminal type | Screw Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| weee b2c / b2b | Business To Business |
| number of poles | 3 |
| actuator marking | I / O |
| pollution degree | 2 |
| rohs information | https://library.abb.com/d/9AKK107680A3903, https://library.abb.com/d/2CCC005084D0202 |
| dimension diagram | https://library.abb.com/d/2CCC413003C0201 |
| eplan catalog tree | Electrical engineering / Protection devices / General |
| input voltage type | DC |
| product net length | 81 mm |
| rated current (in) | 63 A |
| rated voltage (ur) | acc. to IEC 60947-2 750 V DC |
| ambient temperature | -25...60 °C |
| built-in depth (t2) | 82.5 mm |
| connecting capacity | Flexible 0...50 mm2Rigid 0...70 mm2 |
| rated frequency (f) | 0 ... 0 Hz |
| degree of protection | IP20 |
| overvoltage category | III |
| accessories available | Yes |
| energy limiting class | 3 |
| ambient air temperature | Operation -25...60 °C |
| tripping characteristic | UC-B |
| type of residual current | standard version |
| environmental information | https://library.abb.com/d/2CCY413207D0203 |
| number of protected poles | 3 |
| rated operational voltage | acc. to IEC 60947-2 750 V DC |
| object classification code | F |
| contact position indication | ON / OFF / TRIP |
| rated insulation voltage (ui) | acc. to IEC/EN 60664-1 1000 V |
| declaration of conformity - ce | https://library.abb.com/d/2CCC005084D0202 |
| rated operational current (ie) | 63 A |
| data sheet, technical information | https://library.abb.com/d/2CCC413003C0208 |
| width in number of modular spacings | 4.5 |
| rated impulse withstand voltage (uimp) | 8 kV |
| rated conditional short-circuit current (inc) | (230 V) 50 kA(400 V) 50 kA |
| rated service short-circuit breaking capacity (ics) | (750 V DC) 50 kA |
| rated ultimate short-circuit breaking capacity (icu) | (750 V DC) 50 kA(230 V) 50 kA(400 V) 50 kA |
