| Weight | 0.225 KG / psc. |
| Commodity number | 85369095 |
| Country of origin | BG |
| Dimensions (WxHxD) | 0.0525x0.085x0.069 m |
| EAN code | 4016779904445 |
| Product group | AR |
| cn8 | 8536 90 95 |
| eclass | V11.0 : 27142301 |
| etim 7 | EC001545 - Main switch for distribution board |
| etim 8 | EC001545 - Main switch for distribution board |
| power loss | at Rated Operating Conditions per Pole 2.03 W |
| cover color | Grey |
| rohs status | Following EU Directive 2011/65/EU |
| switch type | Off |
| actuator type | Toggle |
| terminal type | Screw Terminals |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| weee b2c / b2b | Business To Consumer |
| number of poles | 3 |
| actuator marking | I / O |
| housing material | Insulation Group I, RAL 7035 |
| pollution degree | 3 |
| rohs information | https://library.abb.com/d/2CDK440037D0202 |
| actuator material | Insulation Group II, Red, Sealable |
| mounting position | Any |
| tightening torque | 2 N·m |
| eplan catalog tree | Electrical engineering / Sensor, switch, and pushbutton / Switch , pushbutton |
| input voltage type | AC |
| rated current (in) | 32 A |
| rated voltage (ur) | 415 V12 V Minimum |
| built-in depth (t2) | 69 mm |
| connecting capacity | Flexible 0.75 ... 16 mm2Rigid 0.75 ... 25 mm2Stranded 0.75 ... 25 mm2 |
| operational voltage | Maximum 436 V ACMinimum 12 V AC |
| rated frequency (f) | 50 / 60 Hz |
| screw terminal type | Cable Clamp |
| degree of protection | IP20Enclosure with Cover IP40 |
| electrical endurance | 10000 AC cycle |
| overvoltage category | III |
| utilization category | Switching of mixed resistive and inductive loads, including moderate overloads - frequent actuation (AC-22A) |
| accessories available | No |
| number of contacts co | 0 |
| number of contacts nc | 0 |
| number of contacts no | 3 |
| ambient air temperature | Operation -25 ... +55 °CStorage -40 ... +70 °C |
| environmental conditions | 28 cycleswith 55 °C / 90-96 %and 25 °C / 95-100 % |
| recommended screw driver | Pozidriv 2 |
| rated operational voltage | 415 V AC |
| object classification code | Q |
| mechanical endurance (nendu) | 20000 cycle |
| declaration of conformity - ce | https://library.abb.com/d/2CDK440035D2703 |
| data sheet, technical information | https://library.abb.com/d/2CDC441016D0201 |
| width in number of modular spacings | 3 |
| rated impulse withstand voltage (uimp) | 4 kVat 2000 m 5 kVat Sea Level 6.2 kV |
| resistance to shock acc. to iec 60068-2-27 | 25g / 2 shocks / 13 ms |
| rated conditional short-circuit current (inc) | 10 kA |
| resistance to vibrations acc. to iec 60068-2-6 | 5g, 20 cycles at 5 ... 150 ... 5 Hz with load 0.8 In |
