ABB

2CDE102001R1901

Product type: ILTS-E2D0

D0-fuse disconnector ILTS-E2

Datasheet

RoHS Compliant

Description

User-friendly fuse-switch-disconnector in "drawer technology", with latching mechanism and captive fuse link carrier. Fuse can be replaced only if the system is de-energized. Compatible with D02 fuse links and D01 fuse link with reducing piece. Twin box terminal on both sides and user-friendly installation of cross-wiring in lower terminal. Compatible with auxiliary switch to indicate switching position. ILTS-E2D0

Low Voltage Products and Systems
Modular DIN Rail Products
Protection and Safety Devices
D0 Fuse Sockets and Fuse Switch Disconnectors

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 2CDE102001R1901.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.92 KG / psc.
Commodity number	85369095
Country of origin	DE
Dimensions (WxHxD)	0.054x0.09x0.07 m
EAN code	4016779653480
Product group	AR
cn8	8536 90 95
eclass	V11.0 : 27142301
etim 7	EC000277 - D0-system switch disconnector
etim 8	EC000277 - D0-system switch disconnector
remarks	Twin-function terminal for simultaneous connection of two conductors (35 mm2 and 16 mm2) or conductor and busbar directly via clamp or with connector sleeve
fuse type	Neozed
standards	EN 60947-1EN 60947-3
power loss	11 W
rohs status	Following EU Directive 2011/65/EU
current range	2-63 A
terminal type	Double Clamp
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
weee b2c / b2b	Business To Consumer
vde certificate	https://library.abb.com/d/9AKK108466A3190
rohs information	https://library.abb.com/d/2CDK440011K0201
dimension diagram	https://library.abb.com/d/9AKK108466A7984
enclosure material	Halogen-, phosphor-, silicone-, CFC-free thermoplast
eplan catalog tree	Electrical engineering / Sensor, switch, and pushbutton / Switch , pushbutton
rated current (in)	63 A
rated voltage (ur)	400 V AC130 V DC
connecting capacity	Stranded 1.5 ... 35 mm2
rated frequency (f)	50 / 60 Hz
ambient air temperature	Operation -5 ... +40 °C
fire and smoke standards	UL 94
environmental information	https://library.abb.com/d/2CDU400027D0201
number of protected poles	2
rated operational voltage	400 V AC130 V DC
declaration of conformity - ce	https://library.abb.com/d/2CDK447006D0402
comparative tracking index (cti)	Material group IIIa: 175V ≤ CTI < 400 200 V
rated operational current dc-22b	(130 V) 63 A
data sheet, technical information	https://library.abb.com/d/No document needed
rated operational current ac-22b (ie)	(400 V) 63 A
