2CSG163030R4022

Product type: DMTME-I-485-96

DMTME-I-485-96 Multimeter

Datasheet

Description

DMTME-I-485-96 is a 96x96mm front-panel digital multimeter for measurement of main electrical parameters, with two digital outputs and embedded RS485.

Low Voltage Products and Systems
Modular DIN Rail Products
Energy Efficiency Devices
Network Analyzers and Multimeters

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 2CSG163030R4022.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.42 KG / psc.
Commodity number	90303100
Country of origin	RO
Dimensions (WxHxD)	96x26.5x103 mm
EAN code	8012542046851
Product group	AY
cn8	90303100
eclass	V11.0 : 27200307
etim 7	EC001194 - Power quality analyser
etim 8	EC001194 - Power quality analyser
accuracy	Active Energy ±1%
dimensions	96 mm x 96 mm
i/o option	2 digital outputs
rohs status	Following EU Directive 2011/65/EU
current type	Mains
communication	Modbus RTU
mounting type	Front panel (96x96 mm)
voltage range	10...500 V
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
current rating	5 A
weee b2c / b2b	Business To Consumer
number of phases	Three-phase
rohs information	https://library.abb.com/d/2CSC445014K270
type of indicator	Digital
rated voltage (ur)	3 x 230 (400) V
additional information	CT (5A)
ambient air temperature	Operation 0 ... 50 °C
number of input channels	Number of voltage input channels: 3Number of current input channels: 3
environmental information	https://library.abb.com/d/2CSC445014K270
object classification code	P
power consumption (@pcons)	6 V·A
number of digital in/outputs	2 Digital Outputs
declaration of conformity - ce	https://library.abb.com/d/9AKK106713A5703
data sheet, technical information	https://library.abb.com/d/9AKK107046A0430
