| Weight | 0.247 KG / psc. |
| Commodity number | 85361010 |
| Country of origin | RO |
| Dimensions (WxHxD) | 0.035x0.085x0.064 m |
| EAN code | 8012542008835 |
| Product group | AR |
| cn8 | 85361010 |
| eclass | V11.0 : 27142121 |
| etim 7 | EC002705 - Holder for cylindrical fuse |
| etim 8 | EC002705 - Holder for cylindrical fuse |
| fuse size | 10x38 mm |
| lock type | Padlockable when open |
| standards | IEC 60947-3 |
| dimensions | 2 module |
| power loss | at Rated Operating Conditions per Pole 3 W |
| rohs status | Following EU Directive 2011/65/EU |
| sealing type | Sealing Wire |
| mounting type | DIN rail |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| bv certificate | https://library.abb.com/d/9AKK108467A0330 |
| lr certificate | https://library.abb.com/d/9AKK107991A7313 |
| ul certificate | https://library.abb.com/d/9AKK107992A1039 |
| weee b2c / b2b | Business To Consumer |
| ccc certificate | https://library.abb.com/d/9AKK108467A0340 |
| eac certificate | https://library.abb.com/d/9AKK107992A1034 |
| imq certificate | https://library.abb.com/d/9AKK108467A0324 |
| krs certificate | https://library.abb.com/d/9AKK108467A0337 |
| number of poles | 2 |
| options provided | No |
| rohs information | https://library.abb.com/d/2CSC444011K2701 |
| e-number (sweden) | 2318051 |
| tightening torque | 2...2.5 N·m |
| e-number (finland) | 3017005 |
| rated voltage (ur) | acc. To IEC 400 Vacc. To UL 690 V |
| built-in depth (t2) | 64 mm |
| connecting capacity | Rigid 2x5 mm2Stranded 2x2-5 mm2 |
| rated frequency (f) | 50/60 Hz |
| certification agency | IMQ, BV, Korean register, CCC, EAC |
| degree of protection | IP20 |
| utilization category | Connecting and disconnecting under no-load conditions - occasional actuation (AC-20B)Switching of mixed resistive and inductive loads, including moderate overloads - occasional actuation (AC-22B) |
| material of conductor | Copper |
| ambient air temperature | Operation -5...+40 °CStorage -25...+70 °C |
| recommended screw driver | Pozidriv 2 |
| environmental information | https://library.abb.com/d/See RoHS Information |
| number of protected poles | 2 |
| rated operational voltage | AC-20B 690 V|AC-22B 400 V |
| connecting capacity ul/csa | Rigid 2x10 AWGStranded 2x14-10 AWG |
| object classification code | F |
| operating humidity (rhamb) | max. 90% with temp. +20 °C50% with max. temp. +40 °C |
| rated insulation voltage (ui) | 1 kV |
| declaration of conformity - ce | https://library.abb.com/d/9AKK106713A5623 |
| data sheet, technical information | https://library.abb.com/d/2CSC444002B0204 |
| rated operational current ac (ie) | 32 A |
| width in number of modular spacings | 2 |
| maximum operating altitude permissible | 2000 m |
| resistance to shock acc. to iec 60068-2-27 | 15g / 18 shocks / 13 ms |
| resistance to vibrations acc. to iec 60068-2-6 | 2 to 13 Hz x= 1 mm peak13 to 100 Hz y= 0.7 g peak |
| shock and vibration withstand acc. to iec 61373 | Category 1, Class B |
