| Weight | 0.19 KG / psc. |
| Commodity number | 85363030 |
| Country of origin | RO |
| Dimensions (WxHxD) | 0.053x0.097x0.073 m |
| EAN code | 8012542773429 |
| Product group | AR |
| cn8 | 85363030 |
| eclass | V11.0 : 27142121 |
| etim 7 | EC002705 - Holder for cylindrical fuse |
| etim 8 | EC002705 - Holder for cylindrical fuse |
| fuse size | 14x51 mm |
| lock type | Padlockable |
| dimensions | 2 modules |
| power loss | at Rated Operating Conditions per Pole 5 W |
| rohs status | Following EU Directive 2011/65/EU |
| sealing type | Sealing Wire |
| suitable for | E 90 |
| mounting type | DIN rail |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| bv certificate | https://library.abb.com/d/9AKK108467A0329 |
| lr certificate | https://library.abb.com/d/9AKK108467A0332 |
| ul certificate | https://library.abb.com/d/9AKK107992A1040 |
| weee b2c / b2b | Business To Consumer |
| ccc certificate | https://library.abb.com/d/9AKK108467A0342 |
| eac certificate | https://library.abb.com/d/9AKK107992A1034 |
| krs certificate | https://library.abb.com/d/9AKK108467A0338 |
| number of poles | 2 |
| options provided | With LED |
| rina certificate | https://library.abb.com/d/9AKK107992A0866 |
| rohs information | https://library.abb.com/d/2CSC444011K2701 |
| tightening torque | 3...3.5 N·m |
| rated voltage (ur) | acc. To IEC 690 Vacc. To UL 690 V |
| built-in depth (t2) | 73.26 mm |
| connecting capacity | Rigid 2.5...25 mm2Rigid Stranded|2.5...35 mm2 |
| rated frequency (f) | 50/60 Hz |
| certification agency | BV, Korean register, CCC, EAC, UL |
| degree of protection | IP20 |
| utilization category | Connecting and disconnecting under no-load conditions - occasional actuation (AC-20B) |
| material of conductor | Copper |
| ambient air temperature | Storage -5...+40 °CStorage Operation|-25...+70 °C |
| recommended screw driver | Pozidriv 2 |
| environmental information | https://library.abb.com/d/See RoHS Information |
| number of protected poles | 2 |
| rated operational voltage | AC-20B 690 V |
| object classification code | F |
| operating humidity (rhamb) | max. 90% with temp. +20 °C|50% with max. temp. +40 °C |
| suitable for product class | Fuse holders |
| rated insulation voltage (ui) | 1 kV |
| declaration of conformity - ce | https://library.abb.com/d/2CSC444009D2701 |
| data sheet, technical information | https://library.abb.com/d/2CSC444002B0204 |
| rated operational current ac (ie) | 50 A |
| width in number of modular spacings | 3 |
| resistance to shock acc. to iec 60068-2-27 | 15g 18 shocks 11 ms |
| resistance to vibrations acc. to iec 60068-2-6 | 2 to 13 Hz x= 1 mm peak13 to 100 Hz y= 0.7 g peak |
