| Weight | 0.053 KG / psc. |
| Commodity number | 85369095 |
| Country of origin | DE |
| Dimensions (WxHxD) | 0.018x0.057x0.047 m |
| EAN code | 4053546050202 |
| Product group | AK |
| cn8 | 85363090 |
| eclass | V11.0 : 27130805 |
| etim 7 | EC000941 - Surge protection device for power supply systems |
| etim 8 | EC000941 - Surge protection device for power supply systems |
| version | Plug-in |
| fuse size | 1 modular spacing |
| standards | IEC 61643-31UL14419 Ed5 |
| rohs status | Following EU Directive 2011/65/EU |
| suitable for | To protect the systems against the transient overvoltage (lightning) |
| mounting type | DIN rail (top hat rail) 35 mm |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| arrester class | II |
| ul certificate | https://library.abb.com/d/9AKK108466A1952 |
| weee b2c / b2b | Business To Consumer |
| number of poles | 3 |
| options provided | Solar |
| rohs information | https://library.abb.com/d/9AKK108466A0826 |
| status indicator | Yes |
| discharge current | I (max, 8 / 20 μs) 40 kA |
| voltage rating dc | 1000 V |
| rated voltage (ur) | 1000 V DC |
| mechanical drawings | https://library.abb.com/d/9AKK108466A2020, https://library.abb.com/d/9AKK108466A5300, https://library.abb.com/d/9AKK108466A5301 |
| degree of protection | IP20 |
| number of protected poles | 2 |
| object classification code | 141DCC |
| short circuit withstand icc | 10 kA |
| declaration of conformity - ce | https://library.abb.com/d/9AKK108466A0826 |
| preventive maintenance feature | No |
| voltage protection level ( up) | 3 kV |
| data sheet, technical information | https://library.abb.com/d/No document needed |
| maximum power point (mpp) voltage | 1000 V |
| maximum operating altitude permissible | Without Derating 2000 m |
| voltage protection rating ul/csa (vpr) | Lpe 3 kVLl 3 kV |
| maximum continuous operating voltage (uc) | (L-PE) 1000 V(L-L) 1000 V(L-N) 0 V(N-PE) 0 V |
| maximum continuous operating voltage ul/csa (mcov) | (L-PE) 1000 V(L-L) 1000 V(L-N) 0 V(N-PE) 0 V |
| rated service short-circuit breaking capacity (ics) | 10 kA |
