| Weight | 0.6 KG / psc. |
| Commodity number | 85369095 |
| Country of origin | BG |
| Dimensions (WxHxD) | 0.071x0.096x0.077 m |
| EAN code | 3660308525284 |
| Product group | AK |
| cn8 | 85363090 |
| eclass | V11.0 : 27130805 |
| etim 7 | EC000941 - Surge protection device for power supply systems |
| etim 8 | EC000941 - Surge protection device for power supply systems |
| version | Plug-in |
| fuse size | 4 modular spacing |
| standards | IEC 61643-11 / EN 61643-11 |
| power loss | 49 mW |
| declaration | https://library.abb.com/d/2CTC432056G1701 |
| suitable for | To protect the systems against the transient overvoltage (lightning) |
| mounting type | DIN rail (top hat rail) 35 mm |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| arrester class | II |
| weee b2c / b2b | Business To Consumer |
| cqc certificate | https://library.abb.com/d/9AKK107680A1974 |
| impulse current | I (imp, 10 / 350 μs) 2 kA |
| number of poles | 4 |
| options provided | Residential, commercial building. |
| status indicator | Yes |
| discharge current | Nominal 20 kAMaximum 40 kATotal 160 kANominal (8 / 20 μs) 20 kAI (max, 8 / 20 μs) 160 kA |
| voltage rating dc | 350 V |
| rated voltage (ur) | 230 V AC |
| mechanical drawings | https://library.abb.com/d/2CTC800015F1400.pdf, https://library.abb.com/d/2CTC800015F1401.dxf, https://library.abb.com/d/2CTC800015F1402.stp, https://library.abb.com/d/2CTC800015F1403.igs |
| degree of protection | IP20 |
| number of conductors | 4 |
| transmission standard | Optic |
| auxiliary circuit load | Minimum 12Vdc - 10mAMaximum 250Vac - 1A |
| number of protected poles | 4 |
| object classification code | 141DCC |
| short circuit withstand icc | 100 kA |
| position of neutral terminals | Right |
| declaration of conformity - ce | https://library.abb.com/d/9AKK108466A4617 |
| preventive maintenance feature | Yes |
| voltage protection level ( up) | 1.4 kV(L-N) 2.8 kV(N-PE) 1.4 kV(L-PE) 1.4 kV |
| number of auxiliary contacts nc | 1 |
| number of auxiliary contacts no | 1 |
| short-circuit protective devices | Curve B Breakers ≤ 125 ACurve C Breakers ≤ 125 AgL Type Fuses ≤ 160 AgG Type Fuses ≤ 160 A |
| data sheet, technical information | https://library.abb.com/d/2CTC432309D0201 |
| width in number of modular spacings | 4 |
| nominal ac voltage of the system (uo) | 230 / 400 V |
| temporary overvoltage test value (ut) | 337 V |
| maximum operating altitude permissible | Without Derating 5000 |
| type of low voltage distribution system | TN-S |
| maximum continuous operating voltage (uc) | (L-PE) 275 V(L-L) 440 V(L-N) 440 V(N-PE) 275 V |
| rated service short-circuit breaking capacity (ics) | 100 kA |
