| Weight | 0.114 KG / psc. |
| Commodity number | 85362010 |
| Country of origin | BG |
| Dimensions (WxHxD) | 0.018x0.085x0.062 m |
| EAN code | 7612270939596 |
| Product group | AR |
| cn8 | 85362020 |
| color | Grey |
| eclass | V11.0 : 27142306 |
| etim 7 | EC000188 - Latching relay |
| etim 8 | EC000188 - Latching relay |
| standards | IEC/EN 60669-1IEC/EN 60669-2-2 |
| power loss | 0.32 W |
| ral number | RAL 7035 - Light Grey |
| rohs status | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| contact type | Normally Open (NO) |
| sound db (a) | (@distance 1 m) 60 dB |
| mounting type | DIN rail |
| response time | <3 ms |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| supply voltage | 103.5 ... 126.5 V AC |
| weee b2c / b2b | Business To Consumer |
| eac certificate | https://library.abb.com/d/9AKK107992A1778 |
| vde certificate | https://library.abb.com/d/VDE E29x_40040851 |
| coil consumption | Control Voltage V AC 115 V ACAverage Pull-in Value 50 Hz 0.070 AControl Voltage V DC 60 V DCAverage Pull-in Value 50 Hz 0.105 A |
| impulse duration | Minimum 50 ms |
| options provided | 1NO |
| rohs information | https://library.abb.com/d/2CCC413008D0206 |
| dimension diagram | https://library.abb.com/d/9AKK107992A6188 |
| maximum lamp load | 3000 WFlourescent, Uncorrected Power Factor (cos. 0.5) 1800 WFlourescent, Corrected Power Factor (cos. 0.9): Serial 3000 WFlourescent, Corrected Power Factor (cos. 0.9): Parallel 2500 WFlourescent, Corrected Power Factor (cos. 0.9): Single 1800 WFlourescent, Corrected Power Factor (cos. 0.9): Double 2500 W |
| tightening torque | 1.2 - 1.5 N·m |
| product net length | 62 mm |
| rated current (in) | 16 A |
| built-in depth (t2) | 68 mm |
| connecting capacity | Solid 1 x 1 ... 10 mm2Flexible 2 x 2.5 mm2Flexible with Cable End 1 x 0.75 ... 6 mm2Flexible with Cable Lug 1 x 0.75 ... 6 mm2 |
| rated frequency (f) | 50 Hz |
| number of contacts co | 0 |
| number of contacts nc | 0 |
| number of contacts no | 1 |
| ambient air temperature | Operation -25...+55 °CStorage -40...+70 °C |
| environmental information | https://library.abb.com/d/2CCC441012D0202 |
| maximum switching current | 16 A |
| rated operational voltage | 250 V AC |
| number of main contacts nc | 0 |
| number of main contacts no | 1 |
| object classification code | K |
| current rating, main switch | 16 A |
| rated insulation voltage (ui) | 115 V AC60 V DC |
| declaration of conformity - ce | https://library.abb.com/d/2CCC005102D0201 |
| number of auxiliary contacts nc | 0 |
| number of auxiliary contacts no | 0 |
| climate class reference standards | IEC 60068-2-2 - Deals with dry heat tests applicable both to heat-dissipating and non heat-dissipating specimensIEC 60068-2-30 - Determines the suitability of components, equipment or other articles for use, transportation and storage under conditions of high humidity - combined with cyclic temperature changes and, in general, producing condensation on the surface of the specimen.IEC 60068-2-1 - Deals with cold tests applicable to both non heat-dissipating and heat-dissipating specimens |
| data sheet, technical information | https://library.abb.com/d/2CCC441020C0201 |
| rated control supply voltage (us) | 115 V AC60 V DC |
| rated control circuit voltage (uc) | 115 V AC60 V DC |
| short-circuit current rating (sccr) | 3 kA |
| width in number of modular spacings | 1 |
| rated impulse withstand voltage (uimp) | 4 kV |
