| Weight | 0.11 KG / psc. |
| Commodity number | 85362010 |
| Country of origin | BG |
| Dimensions (WxHxD) | 0.018x0.085x0.058 m |
| EAN code | 7612270939916 |
| Product group | AR |
| cn8 | 85362020 |
| color | Grey |
| eclass | V11.0 : 27142306 |
| etim 7 | EC000188 - Latching relay |
| etim 8 | EC000188 - Latching relay |
| function | Electronic for centralized control |
| standards | IEC/EN 60669-1IEC/EN 60669-2-2 |
| power loss | 0.64 W |
| ral number | RAL 7035 - Light Grey |
| rohs status | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| contact type | Normally Open (NO) |
| sound db (a) | (@distance 1 m) 60 dB |
| frequency (f) | Control Voltage 1 50 ... 50 HzControl Voltage 2 50 ... 50 Hz |
| mounting type | DIN rail |
| response time | <3 ms |
| weee category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| supply voltage | 250...250 V |
| weee b2c / b2b | Business To Consumer |
| eac certificate | https://library.abb.com/d/9AKK107992A1778 |
| vde certificate | https://library.abb.com/d/VDE E29x_40040851 |
| coil consumption | Control Voltage V AC 8 V ACAverage Pull-in Value 50 Hz 1.088 A |
| rohs information | https://library.abb.com/d/2CCC413008D0206 |
| dimension diagram | https://library.abb.com/d/9AKK107992A6189 |
| maximum lamp load | Fluorescent (Duo Circuit) 3200 V·AFluorescent (Parallel Compensated) 3200 V·AFluorescent 4000 V·AIncandescent 4000 W |
| tightening torque | 1.2 - 1.5 N·m |
| product net length | 58 mm |
| rated current (in) | 16 A |
| rated voltage (ur) | 250 V AC |
| built-in depth (t2) | 68 mm |
| rated frequency (f) | 50 Hz |
| number of contacts co | 0 |
| number of contacts nc | 1 |
| number of contacts no | 1 |
| ambient air temperature | Operation -25...+55 °CStorage -40...+70 °C |
| environmental information | https://library.abb.com/d/2CCC441012D0202 |
| maximum switching current | 32 A |
| number of main contacts nc | 1 |
| number of main contacts no | 1 |
| object classification code | K |
| current rating, main switch | 16 A |
| rated insulation voltage (ui) | 8 V AC |
| declaration of conformity - ce | https://library.abb.com/d/2CCC005102D0201 |
| number of auxiliary contacts no | 2 |
| climate class reference standards | IEC 60068-2-2 - Deals with dry heat tests applicable both to heat-dissipating and non heat-dissipating specimensIEC 60068-2-30 - Determines the suitability of components, equipment or other articles for use, transportation and storage under conditions of high humidity - combined with cyclic temperature changes and, in general, producing condensation on the surface of the specimen.IEC 60068-2-1 - Deals with cold tests applicable to both non heat-dissipating and heat-dissipating specimens |
| data sheet, technical information | https://library.abb.com/d/2CCC441020C0201 |
| rated control circuit voltage (uc) | 8 V AC |
| short-circuit current rating (sccr) | 3 kA |
| width in number of modular spacings | 1 |
| rated impulse withstand voltage (uimp) | 4 kV |
