ABB

4TBV853128C0100

Product type: V43BPDJ6

VMS43 MODULAR UNIT (28 modules)

Datasheet

Description

VMS - Modular System Housing. Standard field housing with hinged cover for rail-mounted devices with contact hazard protection and N/PE terminal with innovative connection technology enables quick and easy, as well as tool-free combination of any type. Open housing sides allow optimum access for wiring and mounting even after the housings have been connected. The side openings can be closed with locking or combination flanges. The standard field housing is made of glass fibre reinforced polycarbonate (light grey, RAL 7035). VMS housings are halogen-free, corrosion-resistant. MFRCH43 RE housing 440x320 2R a.14TE KD V43BPDJ6

Low Voltage Products and Systems
Enclosures
General Purpose Enclosures
Boxes
VMS

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 4TBV853128C0100.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	2.9 KG / psc.
Commodity number	85381000
Country of origin	BE
Dimensions (WxHxD)	175x320x440 mm
EAN code	5411815257124
Product group	2D
cn8	8538100090
color	Grey
eclass	V11.0 : 27142408
etim 7	EC000058 - Empty cabinet
etim 8	EC000058 - Empty cabinet
thickness	Door Plate 3 mm
ral number	RAL 7035 - Light Grey
cover style	Closed
mounting type	Surface mounted (plaster)
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
number of rows	2
weee b2c / b2b	Business To Business
cover plate type	Cover
housing material	Plastic
surface finishing	Untreated
rated current (in)	1250 A
built-in depth (t2)	89 mm
enclosure type nema	Type12
degree of protection	IP65
door surface finishing	Transparent
declaration of conformity - ce	https://library.abb.com/d/No declaration needed
data sheet, technical information	https://library.abb.com/d/No document needed
