ABB

7TCA085400R0418

Product type: OVR SLTNL

Überspannungsableiter RK, 296V, 300mA, 20MHz, 1DA, LED Telekommunikation, ISDN, DSL, VDSL2+

Datasheet

Description

Kombinierte Überspannungs-Schutzeinrichtung für Telekommunkationstechnik, geprüft in den Kategorien D, C, B gemäß IEC/EN 61643 für blitzintensive Umgebungen, zur Verwendung an den Blitzschutzzonen LPZ 0 bis 3.

Low Voltage Products and Systems
Modular DIN Rail Products
Surge Protective Devices SPDs
ABB OVR data & signal protection

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 4-5 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 7TCA085400R0418.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.08 KG / psc.
Commodity number	85363010
Country of origin	GB
Dimensions (WxHxD)	0.107x0.105x0.007 m
EAN code	5415022384277
Product group	AK
cn8	8536308000
etim 7	EC000943 - Surge protection device for data networks/MCR-technology
standards	IEC 61643-21
rohs status	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
suitable for	To protect systems against transient overvoltages or surges from lightning and electrical switching events
weee category	5. Small Equipment (No External Dimension More Than 50 cm)
weee b2c / b2b	Business To Business
connection type	Screw Clamp
rohs information	https://library.abb.com/d/9AKK108466A5046
discharge current	I (max, 8 / 20 μs) 10 kA
reach declaration	https://library.abb.com/d/9AKK108466A5047
serial resistance	1 Ω
rated current (in)	750 mA
rated frequency (f)	20 MHz
wire stripping length	9.5 mm
ambient air temperature	Operation -40 ... +80 °C
number of protected poles	3
declaration of conformity - ce	https://library.abb.com/d/7TKK001511
voltage protection level ( up)	298 V
data sheet, technical information	https://library.abb.com/d/9AKK106713A8157
maximum continuous operating voltage (uc)	296 V
