ABB

GHV2501910R0001

Product type: RD7/250

RD7/250 Surge Suppressor 24 … 250 V DC, screw terminal

Datasheet

RoHS Compliant

Description

The RD7/250 is a surge suppressor for contactor coils. Designed to reduce the maximum overvoltage peak value and to limit or even completely eliminate the high pre-damping voltage frequencies for a rated control circuit voltage between 24 ... 250 V. The surge suppressor is equipt with screw terminals and can be mounted on the DC-operated B6 and B7 mini contactor. RD7/250

Low Voltage Products and Systems
Control Products
Contactors
Mini Contactors

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 6-9 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on GHV2501910R0001.
See all ZWOD Sales and Logistics Ltd ABB products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.005 KG / psc.
Commodity number	85389099
Country of origin	CZ
Dimensions (WxHxD)	80x140x5 mm
EAN code	4013614335938
Product group	SA
eclass	V11.0 : 27371010
etim 4	EC000197 - Surge voltage protection
etim 5	EC000197 - Surge voltage protection
etim 6	EC000197 - Surge voltage protection
etim 7	EC000197 - Surge voltage protection
etim 8	EC000683 - Surge protection module
rohs status	Following EU Directive 2011/65/EU
product name	Surge Suppressor
suitable for	BC6BC7KC6TBC7TKC6VBC6VBC6AVBC7VBC7A
bv certificate	https://library.abb.com/d/NoCerNee
gl certificate	https://library.abb.com/d/NoCerNee
lr certificate	https://library.abb.com/d/NoCerNee
abs certificate	https://library.abb.com/d/NoCerNee
dnv certificate	https://library.abb.com/d/NoCerNee
rina certificate	https://library.abb.com/d/NoCerNee
rmrs certificate	https://library.abb.com/d/NoCerNee
rohs information	https://library.abb.com/d/1SAD938516-0001
rated frequency (f)	Control Circuit DC
degree of protection	IP20
ambient air temperature	Operation -25 ... +55 °CStorage -40 ... +80 °C
suitable for product class	Mini Contactors
rated insulation voltage (ui)	690 V
declaration of conformity - ce	https://library.abb.com/d/1SAD938517-0001
declaration of conformity - ukca	https://library.abb.com/d/1SAD938501-1001
data sheet, technical information	https://library.abb.com/d/1SBC100214C0201
rated control circuit voltage (uc)	DC Operation 24 ... 250 V DC
maximum operating altitude permissible	2000 m
