| Weight | 0.37 KG / psc. |
| Commodity number | |
| Country of origin | |
| Dimensions (WxHxD) | 130x125.6x83.7 mm |
| EAN code | |
| Product group | 7023 |
| ram | 128 MB |
| approval | CE UKCA cULus Listed TÜV EAC (Eurasian) |
| etim version | ETIM-7.0 |
| gross weight | 420 |
| purpose of u1 | Module supply |
| purpose of u2 | Periphery supply |
| type of uint1 | DC |
| eclass version | ECLASS-9.1 |
| plug-in memory | SD card |
| terminal style | plug-in |
| time deviation | +/- 10s/day |
| tolerance of u2 | -30 %/+25 % |
| purpose of uint1 | int. system voltage |
| reach compliance | contains min. 1 SVHC-substance |
| application range | Standard/failsafe |
| multi programming | No |
| supply voltage (v) | 24 24 |
| tolerance of uint1 | -2 %/+3 % |
| ambient temperature | -40 70 |
| broad band noise to | EN 50125-3 |
| connection terminal | Screw terminal Spring-loaded terminal |
| emc to standard ... | EN 50121-4 EN 50121-3-2 |
| etim reference group | EG000024 |
| overvoltage category | OV2 |
| power consumption dc | 16 |
| supply voltage 2 (v) | 24 24 |
| iec 61131 programming | No |
| non-volatile variables | No |
| safetynet p cycle time | 2 ... 60 000 ms |
| condensation permitted? | ISO 16750-4 |
| eclass reference feature | 27242207 |
| flex. cond. c/s awg info | 24 - 12 AWG |
| protection type standard | EN 60529 |
| type of supply voltage u1 | DC |
| type of supply voltage u2 | DC |
| uint1 short circuit proof | Yes |
| perm. operating height asl | 2000 m |
| ambient temp. to standard 2 | -40 ... +70 °C |
| ambient temp. to standard 3 | -40 ... +70 °C |
| app. site standard1 railway | EN 50125-3 |
| app. site standard2 railway | EN 61373 |
| climatic suitability to ... | EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 50155 EN 60068-2-78 EN 60068-2-14 |
| freq. broadband noise, rail | 5 ... 150 Hz |
| safetynet transmission rate | 100 MBit/s |
| accel. broadband noise, rail | 0.572 g RMS |
| acceleration broadband noise | 0.23 g RMS |
| ambient temperature standard | EN 50155 |
| connector type safetynet i/f | M12 |
| setting safetynet trans.rate | Automatic |
| standard 2 for ambient temp. | EN 50125-1 |
| standard 3 for ambient temp. | EN 50125-3 |
| standard1 b/band noise, rail | EN 61373 |
| clearance & creepage dist. to | EN 50124-1 |
| potential isolation 1 between | Periphery and module supply |
| potential isolation 2 between | Periphery supply & system V. |
| type of potential isolation 1 | Functional insulation |
| type of potential isolation 2 | Functional insulation |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| app. site to standard1 railway | Track area (1m - 3m) |
| app. site to standard2 railway | Category 1, Class A + B |
| housing material lower section | PC |
| max. curr. contin. oper. uint1 | 2 |
| pollution degree clear.&creep. | PD2 |
