Pilz

328551

Product type: PSS u2 ES 4AO U/I

Datasheet

Description

PSS u2, electronic module, standard, 4 outputs, 2 voltage ranges, -12 - 12 V, -10 - 10 V, with short circuit detection, 2 current ranges, -24 - 24 mA, 0 - 20 mA, with detection of shorts across contacts, 1-row, terminal block PSS u2 T 16 required (not supplied with the system).

Controller
I/O systems
PSSuniversal 2 - I/O modules
PSSuniversal 2 - Standard I/O modules

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 2-3 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 328551.
See all ZWOD Sales and Logistics Ltd Pilz products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.04 KG / psc.
Commodity number
Country of origin
Dimensions (WxHxD)	12.5x110.8x72.5 mm
EAN code
Product group	7088
approval	CE
etim version	ETIM-7.0
gross weight	56
eclass version	ECLASS-9.1
terminal style	plug-in
humidity rating	93 % r. h. at 40 °C
housing material	PC
application range	Standard
ambient temperature	0 60
emc to standard ...	EN 61131-2 (Zone B)
etim reference group	EG000024
overvoltage category	II
acc. shock to standard1	150 m/s²
condensation permitted?	Not permitted
eclass reference feature	27242604
protection type standard	EN 60529
type of analogue outputs	Current Voltage
vibration to standard ...	EN 60068-2-6
number of analogue outputs	4
perm. operating height asl	2000 m
climatic suitability to ...	EN 60068-2-30 EN 60068-2-2 EN 60068-2-1 EN 60068-2-78 EN 60068-2-14
potential isolation outputs	No
ambient temperature standard	EN 60068-2-14
resolution, analogue outputs	16
signal range analog i-output	0 .. 20 mA
storage temperature standard	EN 60068-2-1/-2
clearance & creepage dist. to	EN 61131-2
climatic suitability standard	EN 60068-2-78
potential isolation 1 between	Analogue o/p and module supply
potential isolation 2 between	Anal. o/p and periph. supply
potential isolation 3 between	Periphery and module supply
signal range analog u- output	0 .. 10 V
type of potential isolation 1	Functional insulation
type of potential isolation 2	Functional insulation
type of potential isolation 3	Functional insulation
weee classifikation (08/2018)	5 devices (feed size < 50cm)
pollution degree clear.&creep.	2
