| Weight | 2.41 KG / psc. |
| Commodity number | 85258019 |
| Country of origin | DE |
| Dimensions (WxHxD) | 95x90x192 mm |
| EAN code | |
| Product group | 7043 |
| approval | UL Listed CE UKCA TÜV |
| espe type | 4 |
| cable lines | Cable sets |
| etim version | ETIM-7.0 |
| gross weight | 2680 g |
| reaction time | 4.65 ms |
| eclass version | ECLASS-9.1 |
| connection type | M12 4-pin |
| humidity rating | 93 % r. h. at 40 °C |
| sensor principle | optical |
| max. cable length | 20 m |
| ul enclosure type | 1 |
| supply voltage (v) | 5 V |
| ambient temperature | 0 - 50 °C |
| emc to standard ... | EN 61496-1 EN 61000-6-4 |
| operating range (m) | 0.1 - 13 m |
| power consumption dc | 0.8 W |
| used wavelength range | 510 - 550 nm |
| acc. shock to standard1 | 10g |
| condensation permitted? | Not permitted |
| eclass reference feature | 27310101 |
| protection type standard | EN 60529 |
| type of supply voltage u1 | DC |
| vibration to standard ... | EN 60068-2-6 |
| resolution protection type | Finger |
| housing material upper part | Aluminium |
| ambient temperature standard | EN 60068-2-14 |
| storage temperature standard | EN 60068-2-1/-2 |
| climatic suitability standard | EN 60068-2-78 |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| max. width of the detect. zone | 44 mm |
