| Weight | 1 KG / psc. |
| Commodity number | 90138090 |
| Country of origin | DE |
| Dimensions (WxHxD) | 95x90x136 mm |
| EAN code | |
| Product group | 7043 |
| approval | CE UKCA cULus Listed TÜV |
| espe type | 4 |
| cable lines | LiYY 4 x 0.25 mm2 |
| etim version | ETIM-7.0 |
| gross weight | 1250 g |
| eclass version | ECLASS-9.1 |
| connection type | M12 |
| humidity rating | 93 % r. h. at 40 °C |
| number of inputs | 2 |
| max. cable length | 75 m |
| ul enclosure type | 1 |
| supply voltage (v) | 24 V |
| ambient temperature | 0 - 50 °C |
| dc voltage at input | 24 V DC |
| emc to standard ... | EN 61496-1 EN 61000-6-4 |
| power consumption dc | 5 W |
| type of light source | High Power LED |
| used wavelength range | 510 - 550 nm |
| acc. shock to standard1 | 10g |
| condensation permitted? | Not permitted |
| eclass reference feature | 27310101 |
| protection type standard | EN 60529 |
| type of supply voltage u1 | DC |
| vibration to standard ... | EN 60068-2-6 |
| potential isolation inputs | No |
| housing material upper part | Aluminium |
| ambient temperature standard | EN 60068-2-14 |
| storage temperature standard | EN 60068-2-1/-2 |
| climatic suitability standard | EN 60068-2-78 |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
