Pilz

680150

Name: 680150
Brand: Pilz
Availability: PreOrder

Product type: PMC Erweiterungskarte PROFINET

Description

Card can be used in PMCtendo DD5 & PMCprotego D.

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 2-3 Weeks Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 680150.
See all ZWOD Sales and Logistics Ltd Pilz products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.086 KG / psc.
Commodity number	85049099
Country of origin	DE
Dimensions (WxHxD)	18.4x140.8x101.8 mm
EAN code
Product group	7074
cas no.	7439-92-1
approval	CE
etim version	ETIM-7.0
gross weight	213 g
profinet type	Slave
eclass version	ECLASS-9.1
rohs directive	2011/65/EU 2015/863/EU
rohs conformity	yes
rohs exceptions	yes
reach compliance	contains min. 1 SVHC-substance
ambient temperature	0 - 40 °C
profinet certification	PNO
%-part of the pollutant	> 0,1%
condensation permitted?	Not permitted
eclass reference feature	27023291
profinet manufacturer id	092Fh
reach included substances	Lead
connector type profinet i/f	RJ45
housing material upper part	Polyester film
housing material front plate	Steel 1.4016
settable trans.rate profinet	100 MBit/s
potential isolation 1 between	PROFINET and system voltage
rohs except.s acc. to direct.	6c
type of potential isolation 1	Functional insulation
weee classifikation (08/2018)	5 devices (feed size < 50cm)
