| Weight | 0.231 KG / psc. |
| Commodity number | 85371091 |
| Country of origin | DE |
| Dimensions (WxHxD) | 45x100x120 mm |
| EAN code | |
| Product group | 7105 |
| approval | CE UKCA cULus Listed KCC KOSHA EAC (Eurasian) TÜV |
| etim version | ETIM-7.0 |
| gross weight | 250 g |
| purpose of u1 | System supply |
| purpose of u2 | Supply of SC outputs |
| eclass version | ECLASS-9.1 |
| humidity rating | 93 % r. h. at 40 °C |
| reach compliance | contains min. 1 SVHC-substance |
| mounting position | horizontal on top hat rail |
| supply voltage (v) | 24 V |
| ambient temperature | 0 - 60 °C |
| connection terminal | Screw terminal Spring-loaded terminal |
| din-rail dimensions | 35 x 7.5 EN 50022 |
| emc to standard ... | EN 61131-2 |
| etim reference group | EG000024 |
| overvoltage category | II |
| power consumption dc | 35 W |
| supply voltage 2 (v) | 24 V |
| acc. shock to standard1 | 15g |
| condensation permitted? | Not permitted |
| galv. isol. config. i/o | No |
| eclass reference feature | 27242207 |
| flex. cond. c/s awg info | 24 - 12 AWG |
| number of digital inputs | 12 |
| protection type standard | EN 60529 |
| potential isolation input | No |
| type of supply voltage u1 | DC |
| type of supply voltage u2 | DC |
| vibration to standard ... | EN 60068-2-6 |
| voltage at 1 n/safe s/c o | UB - 2 V at 0.1 A |
| perm. operating height asl | 2000 m |
| signal level at input at 0 | -3 - +5 VDC |
| signal level at input at 1 | 15 ... 30 V DC |
| housing material upper part | PC |
| number of configurable i/os | 8 |
| number of semicond. outputs | 4 |
| ambient temperature standard | EN 60068-2-14 |
| housing material front plate | PC |
| number of test pulse outputs | 4 |
| potential isolation of s/c o | Yes |
| storage temperature standard | EN 60068-2-1/-2 |
| u input to en 61131-2 type 1 | 24 V DC |
| clearance & creepage dist. to | EN 61131-2 |
| climatic suitability standard | EN 60068-2-30 EN 60068-2-78 |
| potential isolation 1 between | SC output and system voltage |
| type of potential isolation 1 | Basic insulation |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| housing material lower section | PC |
| pollution degree clear.&creep. | 2 |
| s/c output short circuit proof | Yes |
| short circ. prot. n/safe s/c o | Yes |
