| Weight | 0.518 KG / psc. |
| Commodity number | 85371091 |
| Country of origin | DE |
| Dimensions (WxHxD) | 135x94x121 mm |
| EAN code | |
| Product group | 7013 |
| approval | CE UKCA cULus Listed KCC KOSHA EAC (Eurasian) TÜV |
| etim version | ETIM-7.0 |
| gross weight | 537 g |
| purpose of u1 | System supply |
| purpose of u2 | Supply of SC outputs |
| eclass version | ECLASS-9.1 |
| humidity rating | 93 % r. h. at 40 °C |
| reach compliance | contains min. 1 SVHC-substance |
| mounting position | horizontal on top hat rail |
| supply voltage (v) | 24 V |
| ambient temperature | 0 °C |
| connection terminal | Screw terminal Spring-loaded terminal |
| din-rail dimensions | 35 x 7.5 EN 50022 |
| emc to standard ... | EN 61131-2 |
| etim reference group | EG000024 |
| max. no. live inputs | U_B <= 26.4 V : 20 U_B > 26.4 V : 15 |
| overvoltage category | III |
| supply voltage 2 (v) | 24 V |
| potential isolation u2 | Yes |
| acc. shock to standard1 | 15g |
| condensation permitted? | Not permitted |
| galv. isol. n/safe sc o | Yes |
| number of relay outputs | 2 |
| eclass reference feature | 27242207 |
| flex. cond. c/s awg info | 24 - 16 AWG |
| number of digital inputs | 20 |
| protection type standard | EN 60529 |
| voltage ac1 safety cont. | 240 V |
| voltage dc1 safety cont. | 24 V |
| potential isolation input | No |
| type of supply voltage u1 | DC |
| type of supply voltage u2 | DC |
| vibration to standard ... | EN 60068-2-6 |
| voltage ac15 safety cont. | 230 V |
| voltage dc13 safety cont. | 24 V |
| perm. operating height asl | 2000 m |
| signal level at input at 0 | -3 - +5 VDC |
| number of auxiliary outputs | 1 |
| number of cascading outputs | 1 |
| number of semicond. outputs | 4 |
| ambient temperature standard | EN 60068-2-14 |
| galv. isol. casc. aux. s/c o | No |
| housing material front plate | ABS UL 94 V0 |
| number of test pulse outputs | 4 |
| pot. isolation relay outputs | Yes |
| potential isolation of s/c o | Yes |
| storage temperature standard | EN 60068-2-1/-2 |
| u input to en 61131-2 type 1 | 24 V DC |
| clearance & creepage dist. to | EN 61131-2 |
| climatic suitability standard | EN 60068-2-30 EN 60068-2-78 |
| cond.flex awg w/o crimp conn. | 24 - 12 AWG |
| max. current ac1 safety cont. | 6 A |
| max. current dc1 safety cont. | 6 A |
| number of ethernet interfaces | 2 |
| potential isolation 1 between | SC output and system voltage |
| potential isolation 2 between | RL output and system voltage |
| type of potential isolation 1 | Safe separation |
| type of potential isolation 2 | Safe separation |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| housing material lower section | PPO UL 94 V0 |
| max. current ac15 safety cont. | 3 A |
| pollution degree clear.&creep. | 2 |
| s/c output short circuit proof | Yes |
| short circ. prot. n/safe s/c o | Yes |
| signal level at 1 n/safe s/c o | UB - 0.5 VDC at 0.5 A |
| utilisation cat. ac/dc1 stand. | EN 60947-4-1 |
| utilisation cat. ac15/dc13sta. | EN 60947-5-1 |
