| Weight | 4.6 KG / psc. |
| Commodity number | 85044084 |
| Country of origin | AT |
| Dimensions (WxHxD) | 70x345x243 mm |
| EAN code | |
| Product group | 7073 |
| approval | UL Listed CE TÜV EAC (Eurasian) |
| cooling type | Built-on fan |
| etim version | ETIM-7.0 |
| gross weight | 5700 g |
| purpose of u2 | supply |
| eclass version | ECLASS-9.1 |
| humidity class | 1K3 |
| noise emission | 43 dB (A) |
| power derating | 2.5 %/K |
| humidity rating | 85 % r. h. |
| housing material | Galvanised steel |
| reach compliance | contains min. 1 SVHC-substance |
| mounting position | vertical |
| supply voltage (v) | 208 - 480 V |
| ambient temperature | 0 - 40 °C |
| emc to standard ... | EN 61800-3 |
| peak current for 2 s | 4.5 A |
| peak current for 5 s | 3 A |
| supply voltage 2 (v) | 24 V |
| number of sto-enables | 2 |
| ambient temp. derating | 40 - 55 °C |
| purpose of phase range | Mains supply |
| condensation permitted? | Not permitted |
| galv. isol. n/safe sc o | Yes |
| power derating per 100m | 1.5 %/100 m |
| tolerance u2 with brake | +15 % |
| type of analogue inputs | Voltage |
| eclass reference feature | 27023201 |
| number of digital inputs | 4 - 6 |
| protection type standard | EN 60529 |
| ambient temperature class | 1K4 |
| number of analogue inputs | 2 |
| signal range analog input | -10 - 10 V |
| type of supply voltage u1 | AC |
| type of supply voltage u2 | DC |
| vibration to standard ... | EN 60721-3-3 |
| perm. operating height asl | 1000 m |
| potential isolation inputs | yes |
| signal level at input at 0 | -3 - +5 VDC |
| storage temperature change | 20 K/h |
| supply voltage with phases | 3 x 208…3 x 480 V |
| tolerance u2 without brake | +15 % |
| connector type rs rs232 i/f | 9-pin D-Sub male connector |
| cont outp. curr. at 3x230 v | 2 A |
| cont outp. curr. at 3x480 v | 1.5 A |
| number of auxiliary outputs | 2 |
| number of rs 232 interfaces | 1 |
| ambient temperature standard | DIN EN 60721-3-3 |
| connector type ethernet int. | RJ45 |
| cont. outp. curr. at 3x208 v | 2.5 A |
| max. switch-on frequency o/p | 30/h |
| number of canopen interfaces | 1 |
| storage temperature standard | DIN EN 60721-3-1 |
| type of supply voltage range | AC |
| u input to en 61131-2 type 1 | 24 V DC |
| climatic suitability standard | DIN EN 60721-3-3 |
| cont. out. current at 3x400 v | 1.5 A |
| pulse frequ. inverted rectif. | 8 kHz |
| resolution of analogue inputs | 16 Bit |
| v range at intermediate circ. | 900 V DC |
| weee classifikation (08/2018) | 5 devices (feed size < 50cm) |
| connector type encoder/incr.en | 15-pin D-Sub female connector |
| perm. op. height at 1.5% derat | 1000 - 2500 m ASL |
