| Weight | 0.83 KG / psc. |
| Commodity number | 85044082 |
| Country of origin | CZ |
| Dimensions (WxHxD) | 48x124x127 mm |
| EAN code | 875404002734 |
| Product group | A-Standard |
| Derating | 12W/°C for >60°C |
| m_features | AC 100-240V Wide-range input; Width only 48mm; Efficiency up to 95.6%; Excellent partial load efficiency; 20% Output power reserves; Easy fuse breaking - 3 times nominal current for 12ms; Safe Hiccup PLUS overload mode; Active power factor correction (PFC); Minimal inrush current surge; Full power between -25°C and +60°C; DC-OK relay contact; Current sharing feature for parallel use; Remote shut-down |
| DC-OK signal | yes |
| Output power | 480W |
| Power factor | 0.95 |
| Output current | 17.1A at 28V; 20A at 24V |
| Packaging unit | 1 pc |
| Power reserves | 20% Power Boost |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Nominal voltage | 24Vdc |
| AC Input voltage | AC 100 - 240V (-15%/+10%) |
| Adjustment range | 24 - 28V |
| DC Input voltage | DC 110V - 150V (± 20%) |
| E classification | eClass 5.1 27049002; eClass 6.x 27049002; eClass 7.x 27049002; eClass 8.0 27049002; eClass 9.0 27040701; ETIM 4.0 EC000599; ETIM 5.0 EC002540 |
| Efficiency, typ. | 95.6% |
| Connection method | Screw terminals |
| Power losses, typ. | 22.1W |
| Harmonic correction | active |
| Input inrush current | 10A / 4.5A |
| Output current range | 20 - 17.1A |
| Operating temp. range | -25°C to 70°C |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 590000h |
| Ripple and noise voltage max. | 50mVpp |
| Input inrush current limitation | active |
| Weight per unit (excl. packaging) | 830g |
| External input fuse recommendation | B-10A / C-10A |
