| Weight | 0.25 KG / psc. |
| Commodity number | 85044082 |
| Country of origin | CN |
| Dimensions (WxHxD) | 45x75x91 mm |
| EAN code | 875404001690 |
| Product group | A-Standard |
| Derating | 1.5W/°C for >+60°C |
| m_features | 100-240V Wide-range input; NEC Class2 compliant; Adjustable output voltage; Efficiency up to 90.4%; Low no-load losses and excellent partial-load efficiency; Compact design, width only 45mm; Electronic inrush current limitation; Operation down to -40°C; Full output power between -25°C and +60°C; Large international approval package |
| Output power | 60W |
| Power factor | 0.44 |
| Output current | 2.1A at 28V; 2.5A at 24V |
| Packaging unit | 1 pc |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Nominal voltage | 24Vdc |
| AC Input voltage | AC 100 - 240V (-15%/+10%) |
| Adjustment range | 24 - 28V |
| DC Input voltage | DC 110V - 300V (-20%/+25%) |
| E classification | eClass 5.1 27049002; eClass 6.x 27049002; eClass 7.x 27049002; eClass 8.0 27049002; eClass 9.0 27040701; ETIM 4.0 EC000599; ETIM 5.0 EC002540 |
| Efficiency, typ. | 90.4% |
| Connection method | Screw terminals |
| Power losses, typ. | 7.8W 6,4W |
| Input inrush current | 6A |
| Output current range | 2.5 - 2.1A |
| Operating temp. range | -40°C to 70°C |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 1866000h |
| Ripple and noise voltage max. | 50mVpp |
| Input inrush current limitation | active |
| Weight per unit (excl. packaging) | 250g |
| External input fuse recommendation | B-6A / C-3A |
