| Weight | 1.9 KG / psc. |
| Commodity number | 85044082 |
| Country of origin | CN / CZ |
| Dimensions (WxHxD) | 125x124x127 mm |
| EAN code | 875404002093 |
| Product group | A-Standard |
| Derating | 24W/°C for >+60°C |
| m_features | AC 100-240V Wide-range input; Width only 110mm, Weight only 1.9kg; 94.6% Full load and excellent partial load efficiencies; 50% BonusPower, 1440W for up to 4s; 70A High peak current for 10ms for easy fuse Tripping; Safe Hiccup PLUS overload mode; Active power factor correction (PFC); Negligibly low input inrush current; Full power between -25°C and +60°C; Current sharing feature for parallel use; Internal data logging for troubleshooting included.; Remote control of output voltage; DC-OK relay contact; Shut-down input; ATEX and IECEx approved |
| DC-OK signal | yes |
| Output power | 960W |
| Power factor | 0.99 |
| Output current | 22.9A at 42V; 26.7A at 36V |
| Packaging unit | 1 pc |
| Power reserves | 50% BonusPower |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Nominal voltage | 36Vdc |
| AC Input voltage | AC 100 - 240V (-15%/+10%) |
| Adjustment range | 36 - 42V |
| E classification | eClass 5.1 27049002; eClass 6.x 27049002; eClass 7.x 27049002; eClass 8.0 27049002; eClass 9.0 27040701; ETIM 4.0 EC000599; ETIM 5.0 EC002540 |
| Efficiency, typ. | 94.6% |
| Connection method | Screw terminals |
| Power losses, typ. | 54.8W |
| Harmonic correction | active |
| Input inrush current | 17A / 11A |
| Output current range | 26.7 - 22.9A |
| Operating temp. range | -25°C to 70°C |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 300000h |
| Ripple and noise voltage max. | 130mVpp |
| Input inrush current limitation | active |
| Weight per unit (excl. packaging) | 1900g |
| External input fuse recommendation | B-16A / C-10A |
