| Weight | 2.85 KG / psc. |
| Commodity number | 85044082 |
| Country of origin | CN / CZ |
| Dimensions (WxHxD) | 123x124x119 mm |
| EAN code | 875404001195 |
| Product group | A-Standard |
| m_features | Compact and easy to install; Longest buffer time in class; Easy battery access; Stable output voltage in buffer mode; Superior battery management for longest battery life; Temperature compensated battery charging; Comprehensive diagnostics and monitoring functions; Replace battery signal included; Electronically overload and short circuit protected; 50% power reserves; Selectable buffer time limiter |
| Output current | 15A; 10A |
| Packaging unit | 1 pc |
| Product status | Lead time on request |
| Mounting method | DIN rail |
| Nominal voltage | 24Vdc; 22.5Vds |
| Storage element | Built-in lead acid battery |
| DC Input voltage | DC 24V |
| E classification | eClass 5.1 27040603; eClass 6.x 27040603; eClass 7.x 27040603; eClass 8.0 27049201; eClass 9.0 27049201; ETIM 4.0 EC000382; ETIM 5.0 EC000382 |
| Connection method | Spring clamps |
| Allowed battery size | 12V, 5Ah |
| Operating temp. range | 0°C to 40°C |
| Warranty period (months) | 36 |
| MTBF SN 29500 @ 40°C (h) | 886000h |
| Weight per unit (excl. packaging) | 2850g |
| Int. current consumption (incl. charging current) | 1.3A |
| Temperature tracking of the end-of-charge voltage | automatically with temp. sensor |
