Siemens

5SV4342-0MB

Product type: 5SV4342-0MB

RCCB TYPE AC 25/4 30MA 60HZ 4MW

Datasheet

RoHS Compliant

Description

residual current operated circuit breaker, 4-pole, type AC, In: 25 A, 30 mA, Un AC: 400 V, 60 Hz, use of these devices is not permitted in all countries. Observe national installation regulations

Energy
Low-voltage - Power distribution
Low-voltage components
Protection, Switching, Measuring and Monitoring Devices
Residual Current Protective Devices
SENTRON Residual Current Protective Devices
Basic Devices
RCCBs

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 15 Days Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 5SV4342-0MB.
See all ZWOD Sales and Logistics Ltd Siemens products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.315 KG / psc.
Commodity number	85362010
Country of origin	DE
Dimensions (WxHxD)	97x85x78 mm
EAN code	4001869529943
Product group	11C
upc	Not available
group code	P310
metal factor	L-A-----
product class	C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit.
quantity unit	1 Piece
product family	RCCBs
net weight (kg)	0,315 Kg
lkz_fdb/ catalogid	LV10
product lifecycle (plm)	PM300:Active Product
export control regulations	AL : N / ECCN : N
surcharge for raw material	see also metal factor (further details are available on the help page)
standard lead time ex-works	70 Day(s)
weee (2012/19/eu) take-back obligation	Yes
compliance with the substance restrictions according to rohs directive	Since: 01.06.2006
