Siemens

7PJ1321-5CC02-0AA0

Product type: 7PJ1321-5CC02-0AA0

7PJ13 TCS RELAY AC/DC BI

Datasheet

RoHS Compliant

Description

7PJ13 trip circuit supervision relay two binary inputs 2NO+2NC contacts self reset type contacts aux voltage range 24-240V AC/DC binary inputs voltage range 40-240V AC/DC four LED indicators 2 BI status, 1 AUX supply 1 TCS healthy <(>&<)> TCS unhea

Energy
Energy Automation and Smart Grid
Protection
Reyrolle
Reyrolle - Accessories
Reyrolle 7PJ13 - Trip circuit supervision relay

Contact Person
Thomas Hoffmann
+49 305 201 4443

sales@zwodltd.com

Payment

Worldwide shipping

Additional Information
Price: Please send request
Request Lead Time: app. 1 Day
Delivery Time: app. 20 Days Estimated delivery time to our warehouse in Berlin
Delivery Terms: FCA Berlin individually for each client according to INCOM TERMS 2025

ZWOD Sales and Logistics Ltd specializes in hard-to-find parts. Please send request a quote and save on 7PJ1321-5CC02-0AA0.
See all ZWOD Sales and Logistics Ltd Siemens products.

Multiples Of: 1

Product Specifications

Product Attribute	Attribute Value
Weight	0.348 KG / psc.
Commodity number	85364900
Country of origin	IN
Dimensions (WxHxD)	106x58x118 mm
EAN code
Product group	18E
upc	Not available
group code	U321
metal factor	see also metal factor (further details are available on the help page)
product class	B: return restricted, please contact your Siemens partner/contact
quantity unit	1 Piece
product family	Reyrolle 7PJ13 - Trip circuit supervision relay
net weight (kg)	0,348 Kg
lkz_fdb/ catalogid	PTD/EA
product lifecycle (plm)	PM300:Active Product
export control regulations	AL : N / ECCN : N
surcharge for raw material	see also metal factor (further details are available on the help page)
standard lead time ex-works	On request
weee (2012/19/eu) take-back obligation	Yes
compliance with the substance restrictions according to rohs directive	Since: 24.03.2020
